7 Specifications
Item ZING C8
Net Weight Approx. 17.4 lbs (7.9 kg)
Weight and
Approx. 31.5 × 13.7 × 33.4 in
Size
Length × Width × Height
(800 × 350 × 850 mm)
Payload 44–110 lbs (20–50 kg)
Rider
Recommended Age 6–12 yrs.
Requirement
Recommended Height 3'9"–4'9" (115–145 cm)
Max. speed Approx. 10 mph (16 km/h)
Typical Range Approx. 6.2 miles (10 km)
[1]
Traversable Terrain Flat surface, paved road; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
Vehicle
Operating Temperature 14–104°F (-10–40°C)
Parameters
Storage Temperature -4–122°F (-20–50°C); 41–86°F (5–30°C) recommended
IP Rating IPX4
Charging time Approx. 3 h
Battery Type Lithium-ion battery
Nominal Voltage 21.6 V
Battery Pack
Charging Temperature 32–113°F (0–45°C); 50–95°F (10–35°C) recommended
Nominal Capacity / Energy 2500 mAh / 54 Wh
Battery Management System Over-heating, short circuit, over-current and over-charge protection
Nominal Power 120 W (0.12 kW)
Motor
Max. Power 180 W (0.18 kW)
Input Voltage 100—240 V~
Max. Output Voltage 25.2 V
Battery
Charger
Rated Output 24.2 V
Output Power 24.2 W (0.02 kW)
Braking Method Hand-operated brake
Tires Solid tire; material: synthetic rubber
Others
Frame Material Steel
Handlebar Material TPR
Foot Pad Material Sandpaper
09
ZING C10 ZING C15E
Approx. 17.9 lbs (8.1 kg) Approx. 23.4 lbs (10.6 kg)
Approx. 31.5 × 15.7 × 37.4 in Approx. 36.2 × 15.7 × 40.2 in
(800 × 400 × 950 mm)
(920 × 400 × 1020 mm)
8–14 yrs. 10+ yrs.
4'3"–5'3" (130–160 cm) 4'7"–5'10" (140–180 cm)
Approx. 12.4 miles (20 km)
Approx. 6 h
5000 mAh / 108 Wh
150 W (0.15 kW)
260 W (0.26 kW)
1.0 A
Silicone
[1]Typical Range: tested while riding with a full battery, 110 lbs (50 kg) load, 77°F (25°C), 60% of max. speed on average
ZING C20
on pavement.
* Some of the factors that affect range include: rider weight, number of starts and stops, ambient temperature, etc.
8 Maintenance
Maintenance should be carried out by an adult regularly.
Cleaning
Use a soft and wet cloth to clean. Stains hard to remove can be scrubbed with a toothbrush and toothpaste, then wiped off
with a soft and wet cloth.
To prevent jamming to the wheels, wheel bearings, or brakes, please clean and check these areas (as shown in the gray
highlighted areas below) for dirt and other foreign objects.
1
First clean up the foreign objects, and then wipe clean with a soft wet cloth. Lubricate both sides of the bearing with
lubricating oil or machine oil. If the problem still exists, please contact customer service.
CAUTION: To avoid the accumulation of foreign objects, DO NOT ride on muddy, dusty, grassy or slippery roads.
Do not clean your scooter with alcohol, gasoline, acetone, or other corrosive/volatile solvents. These substances may
damage the appearance and internal structure of your scooter. Do not wash your scooter with a power washer or hose.
2
Wheel bearing
