Stand-alone mode
Automatic mode
In automatic mode, 6 show programs are available that run at an adjustable speed.
1
Press the MENU button so many times until AUTO is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (01–06). Confirm with the
ENTER button.
2
Press the MENU button so many times until SPEED is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from 01 (slow) to 09
(fast). Confirm with the ENTER button.
Sound control
Via the integrated microphone the unit can perfectly reproduce the show programs to the rhythm of the
music (sufficient bass provided).
1
Press the MENU button so many times until SOUND is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (01–04). Confirm with the
ENTER button.
2
Press the MENU button so many times until SENSITIV is indicated in the display. Confirm with the
ENTER button. Use the buttons UP and DOWN to Adjust the microphone sensitivity to the volume of the
music (01 = low, 09 = high).
3
Press the MENU button so many times until SPEED is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from 01 (slow) to 09
(fast). Confirm with the ENTER button.
4
If you enable the silent scene mode (on setting) in menu item SILENT, the LEDs will be switched off if
the volume is too low or if there is no sufficient bass beat. If you disable this mode (off setting) the LEDs
remain on during periods without music.
White color setting
The mode COLOR offers the possibility of individually adjusting the brightness of the warm white LED. The
device radiates constantly with this brightness.
1
Press the MENU so many times until COLOR is indicated in the display. Confirm with the ENTER button.
2
Now the display indicates the letters WW for the warm white color and the corresponding brightness
value. Use the buttons UP and DOWN to adjust the desired brightness.
3
Confirm with the ENTER button. Then you can set CW for the cold white color and the corresponding
brightness value.
Color temperature
In the TEMPERAT mode the device will constantly emit white light. The color temperature of the light beam
is adjustable.
1
Press the MENU button so many times until TEMPERAT is indicated in the display. Confirm with the
ENTER button.
2
Use the buttons UP and DOWN to adjust the desired color temperature (see menu structure). Confirm
with the ENTER button.
Total brightness
Menu DIMMING allows adjusting the total brightness for all stand-alone operating modes.
1
Press the MENU button so many times until DIMMING is indicated in the display. Confirm with the
ENTER button.
2
Use the buttons UP and DOWN to adjust the desired brightness (01 = dark, 99 = bright). Confirm with the
ENTER button.
