Conducting a functional test
Setting the switching duration
Here you can set how long the loads connected to AR-
The brightness sensor must not be covered up.
|
GUS are switched on for. When a movement is detected,
the load is switched on and stays switched on until the
A
set period has elapsed. Every further movement restarts
1
2
the switching duration.
D
B
1s
C
4
3
The ARGUS ignores the light-sensitive switch
|
once the load has been switched on. If the move-
5
ment detector does not switch the load off again,
the reason probably is that the ARGUS constantly
detects further movements and thus keeps restar-
ting the switching duration.
=
1 Turn the controller A on the ARGUS back to posi-
tioin A: The ARGUS is ready to use.
Blocking out individual areas
Using the four segments supplied, you can block out un-
The functional display lights up each time move-
|
wanted zones and sources of interference from the area
ment is detected.
of detection.
Setting up the ARGUS manually
½
CAUTION
The device could become damaged.
The sensor head should only be rotated until it
reaches the stop and no further. To achieve an
Ensure that the brightness sensor A is not co-
angle "above" the stop, change the direction of
|
vered, as the sensitivity to light is otherwise redu-
rotation.
ced.
1 Align the sensor head in the direction of the area
that is to be monitored.
Resetting the ARGUS
Reset to the factory settings
Under certain circumstances, it may be neccessary to
reset this device to its factory settings and to reconfigure
9°
12°
12°
12°
12°
it:
24°
½
CAUTION
Malfunctions can occur!
When resetting to the factory settings, all the set-
4° 29°
tings and connections for this CONNECT device
are deleted. Maybe the radio system is not work-
8,5° 8,5°
25°
ing any longer and must be reconfigured (See the
separate description of the CONNECT radio sys-
2 From its edge step into the area of detection to see
tem).
whether the ARGUS switches the load and the func-
tional display as required.
1 Turn the controller A on the ARGUS to position C.
Setting the sensitivity
2 After approx. 1 s the LED flashes short: The device
has now been reset to its factory settings.
Here you can infinitely set the distance up to which AR-
GUS detects movements (any distance up to max.
16 m).
Radio ARGUS in the CONNECT radio
system
As a component of the radio system CONNECT you can
connect the ARGUS with 5 additional CONNECT devic-
es.
If you want to connect the ARGUS with other
|
CONNECT devices (exepted the radio ARGUS
220 CONNECT), you should do this connection
Setting the brightness threshold
via the CONNECT radio USB data interface (with
Here you can infinitely set the ambient brightness level at
a corresponding PC) and the CONNECT radio
which the ARGUS detects movements and triggers a
configurator.
switching procedure.
1 Turn the controller A on the ARGUS to position B:
– Moon symbol (night operation): The ARGUS will only
The learning mode is activated.
detect movements during the hours of darkness (ap-
prox. 3 lux).
– Sun symbol (day and night operation): The ARGUS
detects movements up to approx. 1000 lux.
3 LUX
1000 LUX
What should I do if there is a problem?
You can analyse and check faults throughout the
|
radio system with the help of the CONNECT radio
USB data interface (on a suitable PC) and the
CONNECT radio configuration tool.
40
80
40
80
The device is not reacting to the transmitter
20
3
20
3
• Make sure that the maximum range is not exceeded
8
8
1s
1s
min
min
and that there are no metal surfaces such as metal
1,2 sec
8 min 10 sec
cabinets in the radio transmission path.
• If necessary, check that the device is connected cor-
rectly to the supply voltage.
• Make sure that the device is not in programming
mode. (If the LED is constantly flashing or constantly
lit up, this is the case).
• If necessary, repeat the programming process again.
Technical data
Remote control
Channels:
1
Radio frequency:
868 mHz
Range
Free field: up to 100 m
A
Indoors: up to 30 m
Battery:
1 lithium button cell (CR 2450N)
Display elements:
Status-LED
ARGUS
1
2
Nominal voltage:
AC 230 V ±10%, 50 Hz
Fuse:
Protect the ARGUS using a 16 A
circuit breaker.
Max. switching
current:
16 A, AC 230 V, cosϕ = 1
Nominal output
Incandescent
lamps:
AC 230 V, max. 2000 W
Halogen lamps:
AC 230 V, max. 2000 W
Fluorescent lamps: AC 230 V, max. 1200 W,
uncompensated
Capacitive load:
35 µF
Transformer load:
max. 600 VA
Power consumption: < 1 W
Connecting terminals: for 2x1.5 mm
id conductor, stripped length
14 mm
External diameter of
one cable:
max. 14.5 mm
Angle of detection:
220°
Range:
max. 16 m
Number of levels:
7
Number of zones:
112 with 448 switching seg-
ments
Minimum mounting
height:
1.7 m
Recommended
mounting height:
2.5 m
Sensitivity:
infinitely adjustable
Light sensor:
infinitely adjustable externally,
from appr. 3 lx to appr. 1000 lx
Switching duration:
externally adjustable in 6 levels
of approx. 1 s to appr. 8 min
Possible settings for
sensor head
Wall mounting:
9° up, 24° down, 12° left/right,
± 12° axial
Ceiling mounting:
4° up, 29° down, 25° left/right,
± 8.5° axial
Type of protection:
IP 55 at an angle of inclination
from 15° to 90°
EC directives:
LV guideline 2006/95/EC
EMC directive 2004/108/EC
Information for experienced users who want to use this
device with Z-wave compatible devices from other man-
ufacturers:
Z-wave device type Enhanced Slave
Learn-Mode:
Turn the controller A on the AR-
(for integration into
GUS to position B. LED flashes
Z-wave systems of
for a period of approx. 6 s
other manufacturers)
Transmit „Node Info
Frame":
Turn the controller A on the AR-
GUS to position B
List of functions
Parameter number
Power-on time
181, 182
Association Group
1
Master (Output Light Control)
2
Report (Output „Status Report")
Z-wave designation CONNECT designation
Inclusion
Program (transmits Node Info
Frame), see the separate de-
scription of the CONNECT radio
system
Exclusion
Reset to the factory settings;
complete programming
Primary
Device with system administra-
ton
This device can be used with other Z-wave com-
|
patible devices; also with devices from other ma-
nufacturers. Each Z-wave compatible device can
be added to a Z-wave system and also works as
a router unless the routing of orders is supported.
The configuration of a CONNECT radio system is
described in the separate "CONNECT radio sys-
tem" description. Some programming is only pos-
sible with devices that are compatible with the
CONNECT radio system.
Merten GmbH
Merten GmbH, Solutions for intelligent buildings, Serv-
ice Center, Fritz-Kotz-Str. 8, Industriegebiet Bomig-
2
2
or 2x2.5 mm
rig-
West, D-51674 Wiehl
Phone: +49 2261 702-204
Fax:
+49 2261 702-136
E-Mail: servicecenter@merten.de
Internet: www.merten.com
If you have technical questions, please contact our
InfoLine:
Phone: +49 1805 212581* or +49 800 63783640
Telefax: +49 1805 212582* or +49 800 63783630
E-Mail: infoline@merten.de
*fee required
