To navigate the transmitter menu:
1. Press the key to enter the menu.
2. Use the or keys to scroll through the menu options.
3. Press the key to enter the option's submenu.
4. Use the or keys to scroll through the submenu options.
5. Press the key to return to the previous level or exit the menu.
6. Press the key to return to the main operation screen.
Examples of using the menu, selecting options
and making changes:
Language
To select your preferred menu language:
1. Press the key to enter the menu.
2. Scroll to the LANG menu using the
3. Press the key (on the locator) or the
4. Scroll up or down to select your preferred language.
5. Press the key to accept your selection and return to the main menu.
6. Press the key to return to the main operation screen.
Power / mains frequency (locator only)
To select the correct frequency (50 or 60Hz) for your country or region's power supply:
1. Press the key to enter the menu.
2. Scroll to the POWER menu using the
3. Press the key to enter the POWER menu.
4. Scroll up or down to select the correct frequency.
5. Press the key to accept your selection and return to the main menu.
6. Press the key to return to the main operation screen.
Units (locator only)
The RD8000 locator allows you to work in Metric or Imperial (US customary) units.
To select your preferred units of measurements:
1. Press the key to enter the menu.
2. Scroll to the UNIT option using the
3. Press the key to enter the UNIT submenu.
4. Scroll up or down to select Metric or Imperial units.
5. Press the key to accept your selection and return to the main menu.
6. Press the key to return to the main operation screen.
or keys.
key (on the transmitter) to enter the LANG menu.
or keys.
or keys.
12
Batteries
The locator and transmitter are battery powered.
The RD8000 locators are provided with a rechargeable Lithium-ion (Li-Ion) battery
pack as standard. The RD8000 locators can also be powered using good quality D-cell
alkaline or NiMH batteries.
Transmitters can be powered by D-cell alkaline batteries (as standard), D-cell NiMH
batteries, or by an optional accessory Li-Ion battery pack. Alternatively, you can power
the transmitter from a mains or vehicle power source using a Radiodetection supplied
optional accessory adapter.
If using D-Cells it is important to set the system to match the currently installed battery
type to ensure optimal performance and correct battery level indication.
To set your battery type:
1. Press the key to enter the menu.
2. Scroll to the BATT menu using the
3. Press the key (on the locator) or the
BATT menu.
4. Scroll up or down to select the correct battery type.
5. Press the key to accept your selection and return to the main menu.
6. Press the key to return to the main operation screen.
When using alkaline batteries Eco mode can be selected to maximize their usage. When
Eco mode is selected the transmitter automatically reduces its max power output when
the batteries cannot longer supply enough energy.
Shutting down
To switch the locator or the transmitter off, press and hold the
goes blank.
Locating pipes and cables
Passive Frequencies
Passive frequency detection takes advantage of signals that are already present on buried
metallic conductors. The RD8000 supports four types of passive frequencies: power,
radio, CPS* and Cable TV (CATV)* signals. You can detect these frequencies without the
aid of the transmitter.
*Model specific.
or arrows.
key (on the transmitter) to enter the
key until the screen
