Before using the product, please read the operating instructions, even if you are already familiar with the use of a similar type
of products. Use the product only as described in these operating instructions. Keep the manual for further use.
At least for duration of the warranty, it is recommended to keep the original packaging, including the inner packaging material,
the cash receipt and the warranty card. In the case of transport, wrap the device and put back in the original manufacturers
box, ensuring maximum protection of the product (eg dispatching to the service center).
Cooling and heating box 19 L – 12/24/230V DOUBLE
Portable cooling box with heating capability, powered by 12V or 24V car cigarette lighter socket or by 230V mains. Ideal com-
panion for traveling, holidays, picnic and even for shopping.
It is a thermoelectric cooling box with a twin fan cooling, system which is free of any freons. It allows for 15 – 19°C lower inner
temperatures then the ambient temperature (measured at 25°C). In addition, the system is equipped with a heating mode
where it is possible to keep the temperature inside the box around 50 – 65°C.
The cooling box is equipped with a display that shows the internal temperature. It also has a low noise level, which can also
be suppressed by switching to MUTE mode, where the fan operation is optimized so that the noise level is as low as possible.
Purpose of use
• Device, suitable for cooling the food and beverages.
• This device was designed for a 12/24 V car socket (ciga-
rette lighter) or conventional 230 V power supply.
• The cooling system of this device is based on thermoe-
lectric basis of Peltier's phenomenon, with a fan cooling
system, free of any freons.
Instructions for use:
• Turn the main switch on the control panel to OFF position.
• Select the cable according to the required power supply
(12/24V or 230V). Plug the cable into the appropriate
connector (cables cannot be swaped between 12/24 and
230V).
• When connecting to a 12V or 24V socket, the power supply
changes automatically.
• Plug the cable into the cooling box.
• If you use 12 / 24V cable for a cigarette lighter socket, start
the car engine.
• Set the desired cooling level (blue area) or heating (red
area) with rotary selector on the control panel.
• Turn the main switch on the control panel to ON position.
• The cool box slowly starts to cool the contents.
• If necessary, the AUTO / MUTE switch can be switched for
quiet mode (MUTE), where the fan is operating in the op-
timized mode so the noise level keeps as low as possible.
• Achieving the specified cooling temperatures, depends on
the ambient air circulation and mostly on ambient temper-
ature.
2
INSTRUCTIONS FOR USE
Cooling:
The best cooling results are achieved, when the box is filled
with food and beverages (in hygienic packages) that have
been precooled, for example in the refrigerator. Filling re-
mains cool and continue to cool more if you let the device
turned on. However, the coolbox is not a freezer! When device
is turned on for a long time, it can reach a temperatures of
21 - 23°C under ambient temperature (measured at ambient
temperature of 25°C).
Heating:
If the box is set to heating mode, it is possible to reach tem-
peratures from +50°C to +65°C. The box is designed to keep
hot food in a warm state - but not to heat cold food! At the
same time, box will ensure that the drinks do not freeze in
winter time.
Maintenance of the device:
Unplug the power cord, before cleaning!
For hygienic reasons, wipe the box with a sponge (slightly
soaked in a mild detergent solution) before first use. Then,
clean the interior with a sponge soaked in clean water and
wipe it dry.
Wipe the box with soft cloth to avoid scratching of the sur-
face. Use a soft cloth soaked in non-aggressive detergent to
remove stronger dirt. Never use scouring side of dish sponge,
solvents, or alcohol when cleaning.
Warning: Never clean the appliance under running water or
in dishwasher.
item 07 130
