34 EUROLIVE B208D/B208D-WH/B210D/B210D-WH/B212D/B212D-WH/B215D/B215D-WH
Specifiche
B208D
Potenza d'uscita dell'amplificatore
Gamma basse frequenze
Potenza RMS 135 W @ 8 Ω
Potenza di picco 160 W @ 8 Ω
Gamma alte frequenze
Potenza RMS 38 W @ 8 Ω
Potenza di picco 42 W @ 8 Ω
Dimensione dell'altoparlante
Dimensione 8"
Ingressi audio
XLR (servo-bilanciato)
Sensibilità
Impedenza d'ingresso
Jack TRS da ¼" (servo-bilanciato)
Sensibilità
Impedenza d'ingresso
Controllo Level
Regolazione ingresso
Max. livello d'ingresso
Connettore Link
Connettore
Dati di sistema
Risposta in frequenza
Frequenza Crossover 24 kHz
Livello pressione sonora max. 113 dB SPL @ 1 m
Limiter
Equalizzatore dinamico
Equalizzatore
HIGH
LOW
Alimentazione
Voltaggio (Fusibile)
120 V, 60 Hz
USA/Canada
(T 4.0 A H 250 V)
240 V~, 50 Hz
UK/Australia
(T 2.0 A H 250 V)
230 V~, 50 Hz
Europe
(T 2.0 A H 250 V)
100 V~, 50-60 Hz
Giappone
(T 4.0 A H 250 V)
Consumo energetico max. 300 Watts
Connessione alimentazione
Dimensioni/Peso
appr. 14,65 x 9,80 x 8,00"
Dimensioni (A x L x P)
appr. 372 x 249 x 205 mm
Peso 14,68 lbs / 6,66 kg
behringer.com
B210D B212D B215D
135 W @ 8 Ω 280 W @ 8 Ω 280 W @ 8 Ω
160 W @ 8 Ω 450 W @ 8 Ω 450 W @ 8 Ω
38 W @ 8 Ω 65 W @ 8 Ω 65 W @ 8 Ω
42 W @ 8 Ω 100 W @ 8 Ω 100 W @ 8 Ω
10" 12" 15"
-40 dBu a +4 dBu
20 k Ω
-40 dBu a +4 dBu
20 k Ω
–∞ a + 30 dB
+22 dBu
connettore XLR
da 65 Hz a 20 kHz
24 kHz 24 kHz 1.9 kHz
max. 113 dB SPL @ 1 m max. 125 dB SPL @ 1 m max. 126 dB SPL @ 1 m
Optical
Controllato da processore
12 kHz / ±15 dB
80 Hz / ±15 dB
120 V, 60 Hz 120 V, 60 Hz 120 V, 60 Hz
(T 4.0 A H 250 V) (T 6.3 A H 250 V) (T 6.3 A H 250 V)
240 V~, 50 Hz 240 V~, 50 Hz 240 V~, 50 Hz
(T 2.0 A H 250 V) (T 3.15 A H 250 V) (T 3.15 A H 250 V)
230 V~, 50 Hz 230 V~, 50 Hz 230 V~, 50 Hz
(T 2.0 A H 250 V) (T 3.15 A H 250 V) (T 3.15 A H 250 V)
100 V~, 50-60 Hz 100 V~, 50-60 Hz 100 V~, 50-60 Hz
(T 4.0 A H 250 V) (T 6.3 A H 250 V) (T 6.3 A H 250 V)
max. 300 Watts max. 600 Watts max. 600 Watts
IEC standard
appr. 18,27 x 11,50 x 9,61" appr. 21,7 x 13,6 x 10,6" appr. 27,2 x 17,3 x 13,2"
appr. 464 x 292 x 244 mm appr. 550 x 345 x 270 mm appr. 690 x 440 x 335 mm
18,77 lbs / 8,52 kg 31,9 lbs / 14,5 kg 45,2 lbs / 20,54 kg
Specificaties
B208D
Vermogensuitgang van de versterker
Laagfrequente bereik
RMS Vermogen 135 W @ 8 Ω
Piekvermogen 160 W @ 8 Ω
Hoogfrequent bereik
RMS Vermogen 38 W @ 8 Ω
Piekvermogen 42 W @ 8 Ω
Afmetingen van de luidspreker
Afmetingen 8"
Audio-ingangen
XLR (servogebalanceerd)
Gevoeligheid
Ingangsimpedantie
¼" TRS-contrasteker (servogebalanceerd)
Gevoeligheid
Ingangsimpedantie
Niveauregeling
Ingangsregeling
Max. ingangsniveau
Linkconnector
Connector
Systeemgegevens van de luidspreker
Frequentiebereik
Overspraakfrequentie 24 kHz
Geluidsdrukniveau max. 113 dB SPL @ 1 m
Begrenzer
Dynamische Equalizer
Equalizer
HOOG
LAAG
Voeding
Spanning (Zekeringen)
120 V, 60 Hz
V.S./Canada)
(T 4.0 A H 250 V)
240 V~, 50 Hz
G.B./Australië
(T 2.0 A H 250 V)
230 V~, 50 Hz
Europa
(T 2.0 A H 250 V)
100 V~, 50-60 Hz
Japan
(T 4.0 A H 250 V)
Energieverbruik max. 300 Watts
Netspanningaansluiting
Afmetingen/Gewicht
ca. 14,65 x 9,80 x 8,00"
Afmetingen (H x B x D)
ca. 372 x 249 x 205 mm
Gewicht 14,68 lbs / 6,66 kg
Quick Start Guide
B210D B212D B215D
135 W @ 8 Ω 280 W @ 8 Ω 280 W @ 8 Ω
160 W @ 8 Ω 450 W @ 8 Ω 450 W @ 8 Ω
38 W @ 8 Ω 65 W @ 8 Ω 65 W @ 8 Ω
42 W @ 8 Ω 100 W @ 8 Ω 100 W @ 8 Ω
10" 12" 15"
-40 dBu ... +4 dBu
20 k Ω
-40 dBu ... +4 dBu
20 k Ω
–∞ ... + 30 dB
+22 dBu
XLR connector
65 Hz ... 20 kHz
24 kHz 24 kHz 1.9 kHz
max. 113 dB SPL @ 1 m max. 125 dB SPL @ 1 m max. 126 dB SPL @ 1 m
Optisch
Processorgestuurd
12 kHz / ±15 dB
80 Hz / ±15 dB
120 V, 60 Hz 120 V, 60 Hz 120 V, 60 Hz
(T 4.0 A H 250 V) (T 6.3 A H 250 V) (T 6.3 A H 250 V)
240 V~, 50 Hz 240 V~, 50 Hz 240 V~, 50 Hz
(T 2.0 A H 250 V) (T 3.15 A H 250 V) (T 3.15 A H 250 V)
230 V~, 50 Hz 230 V~, 50 Hz 230 V~, 50 Hz
(T 2.0 A H 250 V) (T 3.15 A H 250 V) (T 3.15 A H 250 V)
100 V~, 50-60 Hz 100 V~, 50-60 Hz 100 V~, 50-60 Hz
(T 4.0 A H 250 V) (T 6.3 A H 250 V) (T 6.3 A H 250 V)
max. 300 Watts max. 600 Watts max. 600 Watts
Standaard IEC-toestelsteker
ca. 18,27 x 11,50 x 9,61" ca. 21,7 x 13,6 x 10,6" ca. 27,2 x 17,3 x 13,2"
ca. 464 x 292 x 244 mm ca. 550 x 345 x 270 mm ca. 690 x 440 x 335 mm
18,77 lbs / 8,52 kg 31,9 lbs / 14,5 kg 45,2 lbs / 20,54 kg
behringer.com
35
