Addressing

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED C-1 Bar will respond to the controller.
For address setting, press the MODE button until the display shows "A001".
Controlling:
After having addressed the LED C-1 DMX Lighting Controller, you may now start operating it via your lighting
controller.
Note:
After switching on, the LED C-1 DMX Lighting Controller will automatically detect whether DMX 512 data is
received or not. If the data is received, the control LED flashes. If there is no data received at the DMX-input,
the control LED lights up permanently.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the LED C-1
DMX Lighting Controller.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.

DMX-protocol

Control Channels

Channel 1
Value: Option
0-12 Blackout
13-25 Red
26-38 Green
39-51 Yellow
52-64 Blue
65-77 Purple
78-90 Cyan
91-103 White
104-116 Colour change
117-129 Slow flow 1
130-142 Slow flow 2
Channel 2: Speed
0-255 Step Time Value of 1/min up to 100/sec
Channel 3: Flash
0-255 Flash varies from OFF to 20Hz
Value: Option
143-155 Roll chase 1
156-168 Roll chase 2
169-181 Multi colour
182-194 Fast flow 1
195-207 Fast flow 2
208-220 2 colour chase
221-233 2 colour flow
234-246 Colour fade
247-255 Auto run
