Chaser

A chaser is a sequence of different programs (modes) that will be called up one after another. With the
EUROLITE LED C-1 DMX Lighting Controller, you can select up to 13 different chasers.
Selecting a chaser
Press the MODE button and select the desired chaser.
Please Note: In order to switch programs, please set the address in DMX mode to 0.
Press the SET UP button and select the desired Speed and Flash Frequence parameters.
The desired parameter values can be selected via the UP or DOWN buttons.
Mode Option: Possible Colours
Static Colours Blackout, red, green, yellow, blue, violet, cyan, white
Mode Option: SET UP Option
Colour change Speed
Flash Frequence
Slow flow 1 Speed
Flash Frequence
Slow flow 2 Speed
Flash Frequence
Roll chase 1 Speed
Flash Frequence
Roll chase 2 Speed
Flash Frequence
Multi-colour Speed
Flash Frequence
Fast flow 1 Speed
Flash Frequence
Fast flow 2 Speed
Flash Frequence
2 colour chase Speed
Flash Frequence
Colour Sortation
2 colour flow Speed
Flash Frequence
Colour Sortation
Colour fade Speed
Flash Frequence
Autorun Speed
Flash Frequence
System mode Panel Addressing:
Panel Amount:
DMX Addressing
* Please Note: After determining the number of panels being used, or after an address change, the address
must be set once before taking the system into operation for the first time.

Stand Alone operation

In the Stand Alone mode, the LED C-1 DMX Lighting Controller can be used without controller.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
UP/DOWN
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 – 100
1 -- 20
1 -- 100
1 – 100
1 -- 20
1 -- 100
1 -- 100
1 -- 100
1 -- 100
1 – 508 (YES), 0 (NO) *
1 – 1000
1 – 508
