Rasentrimmer_Akku_196064.book Seite 23 Montag, 18. November 2019 9:19 09
Only re-charge the battery pack indoors.
Do not dispose of a battery pack with the
household waste!
Do not dispose of a battery pack in water!
Do not burn the battery pack!
Do not expose the battery pack to sunlight
or increased temperatures!
MAX xx °C MAX xx °C
Personal protective clothing
Wear safety goggles
Wear ear defenders
Wear protective gloves
Wear safety shoes
Wear close-fitting work clothes

Your device at a glance

Note: The actual appearance of your prod-
uct may differ from the illustrations.
Lawn trimmer
► P. 3, item 1
1. On/off switch
2. Safety lock
3. Operating handle
4. Battery pack (not included in the scope of deliv-
ery)
5. Lock for cutting head rotation
6. Protective hood
7. Cutting disk
8. Spacer
9. Cutting insert
10. Cutting head
11. Lock for cutting head inclination
12. Lock for length setting
13. Front handle
► P. 3, item 2
14. Display for remaining capacity
15. Push button for capacity display
16. Locking button
17. Control lights
18. Battery charger (not included in the scope of
delivery)
Scope of delivery
• Operating manual
• Lawn trimmer

Assembly

CAUTION! Risk of injury! On the under-
side of the protective hood there is a sharp
blade designed to cut the thread. Remove
the transportation protection mechanism
after mounting.
► P. 4, item 3
– Slip the protective housing (6) onto the cutting
head as illustrated and allow it to engage
securely.
► P. 4, item 4
– Screw the front handle (13) to the device with the
screw (19).

Operation

Charging the battery pack
Note: Rechargeable battery and charger
are not part of the scope of delivery and are
available optionally from your dealer
(► Accessories – p. 25).
CAUTION! Risk of injury! Comply with all
safety instructions when handling recharge-
able devices.
NOTICE! Risk of damage to the unit! Do
not allow the battery pack to deep dis-
charge.
NOTICE! Risk of damage to the unit! Do
not press the On/Off switch after the device
has deactivated automatically.
Note: The Li-Ion battery pack can be
charged at any time without affecting the
lifetime of the unit. Interrupting the charging
process will not damage the battery pack.
Note: If the battery is fully loaded, the
charger automatically switches over to the
maintenance charge function. The battery
can thus remain in the charger permanently.
The battery pack must be charged prior to the first
start-up (charging time: ► Technical data – p. 25).
– Press in the locking button (16) and remove the
battery from the device.
– Insert the battery pack into the charger.
– Plug the charger into the power supply.
The charging status is displayed by the control
lights (17).
– Slot the battery pack into the device and make
sure it clicks into place correctly.
Checking the remaining capacity of the battery
– Press the button (15).
GB
23
