Low battery voltage:
•
The remaining battery capacity is too low and
the tool will not operate. In this situation,
remove and recharge the battery.
Switch action
Fig.3
CAUTION:
Before installing the battery cartridge into the tool,
•
always check to see that the tool is switched off.
To start the tool, slide the slide switch toward the "I (ON)"
position.
To stop the tool, slide the slide switch toward the "O
(OFF)" position.
Adjusting the orbital stroke rate
Fig.4
The orbital stroke rate is adjustable. To change the orbital
stroke rate, turn the dial between 1 and 6. The higher the
number is, the higher the orbital stroke rate is. Preset the
dial to the number suitable for your workpiece.
NOTE:
The dial cannot be turned directly from 1 to 6 or
•
from 6 to 1. Forcing the dial may damage the tool.
When changing the dial direction, always turn the
dial moving it through each intermediate number.
Lighting up the front lamp
WARNING:
Never look into the light directly. Direct light causes
•
damage to your eyes.
Fig.5
Slide the slide switch toward the "I (ON)" position to light
up the front lamp. The lamp keeps on lighting while the
switch is the "I (ON)" position. The light automatically
goes out after pressing the rear of the slide switch, and
then sliding the slide switch toward the "O (OFF)"
position.
Overload protection
When the tool is overloaded and the tool temperature
reaches a certain level, the front lamp blinks and the tool
automatically stops. Remove a cause of overload to
restart.
Indication lamp
Fig.6
When the remaining battery capacity gets low, the
•
indication lamp blinks.
When the remaining battery capacity gets much
•
lower, the tool stops during operation and the
indication lamp lights up about 10 seconds.
At this time, remove the battery cartridge from the tool
and charge it.
ASSEMBLY
CAUTION:
Always be sure that the tool is switched off and the
•
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing application tool
(optional accessory)
WARNING:
Do not install application tool upside down.
•
Installing application tool upside down may
damage the tool and cause serious personal injury.
Install attachment tool in the correct direction
•
according to your work. Application tool can be
installed at an angle of every 30 degree.
Fig.7
Fig.8
Put an application tool (optional accessory) on the tool
flange so that the protrusions of the tool flange fit in the
holes in the application tool and secure the application
tool by tightening the bolt firmly with the hex wrench.
When using sanding application tool, mount the
application tool on the sanding pad so that it matches
the sanding pad direction.
The sanding pad has a hook and loop type fitting system
which allows easy and rapid fitting of a sanding paper.
As sanding papers have holes for dust extraction, mount
a sanding paper so that the holes in a sanding paper
match those in the sanding pad.
To remove a sanding paper, raise its end and peel it off.
Loosen and remove the application tool installation bolt
using a hex wrench and then take off the application tool.
Fig.9
When using application tools with a different type of
installation section, use a correct adapter (optional
accessory).
Hex wrench storage
Fig.10
When not in use, store the hex wrench as shown in the
figure to keep it from being lost.
