Loading The Racks; Cleaning And Maintenance - Indesit D2F HD624 AS Kurzanleitung

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED flashes rapidly 3 times and beeps will sound. The option will not be enabled.
HALF LOAD - If there are not many dishes to be washed, a half loading
may be used in order to save water, electricity and detergent.
Remember to halve the amount of detergent.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be off.
WATER TAP CLOSED – Alarm
Flashes when there is no inlet water or water tap is closed.
-
PUSH&GO
Push&Go button is an easily distinguishable button that
allows you direct access to the Push&Go program, a wash and dry cycle
that ensures great cleaning performance in a short time. You don't have to
worry which program to choose, Push&Go cycle will do the work for you.

LOADING THE RACKS

UPPER RACK
ADJUSTABLE
(loading example for the
upper rack)
Load delicate and light
dishes: glasses, cups,
saucers, low salad bowls.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY
1 2
A
In case you find foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.indesit.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-
sales Service, please state the codes provided on your product's identification plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identifier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
2
FOLDABLE
FLAPS WITH
POSITION
(loading example for the lower rack)
For pots, lids, plates, salad bowls, cutlery etc.. Lar-
ge plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be
used in a vertical position when arranging plates
or in a horizontal position (lower) to load pans
and salad bowls easily.
3
B
A
C
Please scan the QR code on your product in order to have more detailed information.
DELAY -
The start of the program may be delayed for a period of time
between 0:30 and 24 hours
The DELAY function cannot be set once a wash cycle has been started.
DRAIN OUT - To stop and cancel the active cycle, the Drain Out
function can be used. A long press of START/PAUSE button, will
activate the DRAIN OUT function. The active program will be stopped and
the water in the dishwasher will be drained out.
LOWER RACK
More information in the Daily Reference Guide on website.
CLEANING THE SPRAY ARMS
4
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
CAPACITY: 14 standard place-settings
CUTLERY BASKET
The basket is equipped with top grilles for improved
cutlery arrangement. The cutlery basket should be
positioned only at the front of the lower rack.
Knives and other utensils with sharp edges must be
placed in the cutlery basket with the points facing
downwards or they must be positioned horizontally
in the tip-up compartments on the upper rack.
The lower spray arm may
be removed by pulling it
upwards.
IEC 436
:
400011660753C
01/2023 dk - Xerox Fabriano
