2 - TECHNICAL SPECIFICATIONS

The Series R433 use AM/ASK demodulation;
The Series F433 use AM/ASK demodulation;
Characteristics
Receiver type
Carrier frequency
Local oscillator frequency
Modulation
Input impedance
Channel lenght
Intermediate frequency
Input sensitivity
Local oscillator emissions
Power supply
Consumption
Max applicable power
at relay contacts
User codes max
Operating temperature
IP Grade
Weight
Overall dimensions (mm )
Selflearning radio memorization

3 - MAIN FEATURES

Self-learning and erasing of the transmitter code simply using the transmitter keys, without accessing to the
receiver board;
85 storable transmitter keys;
Display of the stored transmitter keys number;
Display of the code memory position for the last received trasmitter;
Overwrite of the transmitter code stored;
Full memory erasure;
Programmable operation of the relays: monostable, bistable, delay.
Programmable delay of release for the relays from 1 sec. to 10 hours.
4 - INSTALLATION
4.1 - Positioning
The location choice is very important for the best result of the installation.
The following conditions have to be followed:
- Fix the receiver far from interference sources as informatic systems, allarm systems or other radio emissions.
- the distance between 2 receivers should be more than 1.5 m.
Pag. 13
All manuals and user guides at all-guides.com
(Mod. AM) SEL 2641R433C2V
(Mod. FM) SEL 2641F433C2V
Superheterodyne
433.92 MHz
6,6128 MHz
AM/ASK - FM/FSK
50 Ohm
> 25 KHz
10,7 MHz
-115 dBm
< -57 dBm
230 Vac
28 mA
3,5 KW / 230 Vac
85
-20°/+70°C
IP44
400 gr.
140 x 115 x 52
yes
SEL2641R433C2P
SEL2641F433C2P
Tab.2
T H E S M A R T L I V I N G
Superheterodyne
433.92 MHz
6,6128 MHz
AM/ASK - FM/FSK
50 Ohm
> 25 KHz
10,7 MHz
-115 dBm
< -57 dBm
12 - 24 Vac-dc
200 mA @ 24 Vac
260 mA @12 Vac
3,5 KW / 230 Vac
85
-20°/+70°C
IP44
300 gr
140 x 115 x 52
yes
