1 - INTRODUCTION
The receivers ERONE 433 type SEL2641R433-C2V/C2P and SEL2641F433C2V/C2P are superheterodyne
receivers of the series ERONE 433.
The product has been designed for the control of automatic closing systems and anti-burglar systems, thanks to its
very high security coding system (KeeLoq® Hopping code).
The operating frequency is among the European harmonised frequencies; the product fully complies with the EMC
European Regulations (CE).
The code sent by the transmitter changes at every activation, avoiding any scanning and copying risk.
A special algorithm allows to keep synchronysed transmitter and receiver.
The receiver, which makes the activation, once received the transmitter code, has to be connected during the
installation to the device to control (gate, garage door, rolling shutters, awnings, anti-burglar appliances, lighting,
etc.).
The receiver has 2 output relays, with NO (Normally open) and NO/NC (Normally open and normally closed)
contacts.
It can be connected to any type of appliance as gates, garage doors, rolling shutters, lighting, etc.
The max power commutable is 3,5 KW @ 230 Vac for each relay.
The user codes can be memorised both with the receiver buttons and, via radio, in self-learning, using the
transmitter keys.
All the receivers of Erone 433 Series can manage the serial number and the sinchronisation algorithm of
many transmitters.
The receiver is produced in 2 models which differ by the power supply and the modulation :
RX Model
SEL 2641 R433 C2P
SEL 2641 R433 C2V
SEL 2641 F433 C2P
SEL 2641 F433 C2V
All manuals and user guides at all-guides.com
Power supply
12 / 24 Vac-dc
230 Vac
12 / 24 Vac-dc
230 Vac
ENGLISH
Usable transmitters
S2TR2641E2/E4/E2M
SETR2641AM2 / SETR2641TM
S2TR2641F2/F4/F2M
SETR2641FM2
Tab.1
