About this Guide

1.1 Validity
This guide provides all of the information required to safely
use the BES sensor with digital voltage and IO-Link
interface.
It applies to the following models (see Type code on
page 16):
– BES M08EH1-L01C20B-S04G-L04
Order code: BES060Y
– BES M12EH1-L01C40B-S04G-L04
Order code: BES05Y7
BES M12EG1-L01C80F-S04G-L04
–
Order code: BES05ZW
BES M18EH1-L01C80B-S04G-L04
–
Order code: BES05WY
– BES M18EH1-L01C12F-S04G-L04
Order code: BES0601
Read this guide and the other applicable documents
completely before installing and operating the product.
Original User's Guide
This guide was created in German. Other language
versions are translations of this guide.
© Copyright 2022, Balluff GmbH
All contents are protected by copyright. All rights reserved,
including the rights of reproduction, distribution,
processing and translation.
1.2

Other applicable documents

Additional information about this product can be found at
www.balluff.com on the product page, e.g. in the
following documents:
– Data sheet
– Declaration of Conformity
– Disposal
1.3

Symbols and Conventions

Individual action instructions are indicated by a preceding
triangle.
► Instruction 1
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Numbers unless otherwise indicated are decimals
(e.g. 23). Hexadecimal numbers are represented with a
preceding 0x (e.g. 0x12AB).
Note, tip
This symbol indicates general notes.
www.balluff.com
1.4

Explanation of the warnings

Always observe the warnings in these instructions and the
measures described to avoid hazards.
The warnings used here contain various signal words and
are structured as follows:
SIGNAL WORD
Type and source of the hazard
Consequences if not complied with
► Measures to avoid hazards
The individual signal words mean:
DANGER
The general warning symbol in conjunction with the
signal word DANGER identifies a hazard which, if not
avoided, will certainly result in death or serious
injuries.
1.5

Used Technical Terms and Abbreviations

SIO Standard Input Output
english 5
