DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A INDESIT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.indesit.com/register
Before using the appliance carefully read Safety Instructions.
PRODUCT DESCRIPTION
APPLIANCE
7
8
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1
1.
On-Off / Reset button with indicator light
2.
Program selection button with indicator light
3.
Multizone button with indicator light / Tablet (Tab)
4.
Eco program indicator light
5.
Display
6.
Program number and remaining time indicator
7.
Tablet (Tab) indicator light
3
2
4
You can download the Safety Instructions and the User
Manual, by visiting our website docs.indesit.eu and
following the Instructions on the back of this booklet.
1.
Upper rack
1
2.
Foldable flaps
2
3.
Upper rack height adjuster
4.
Upper spray arm
5.
Lower rack
6.
Cutlery basket
3
7.
Lower spray arm
4
8.
Filter Assembly
9.
Salt reservoir
5
10. Detergent and Rinse Aid dispensers
6
11. Rating plate
12. Control panel
10
5
6
7 8
9
10
11
8.
Closed water tap indicator light
9.
Rinse Aid refill indicator light
10. Salt refill indicator light
11. Push & Go button with indicator light
12. Delay button with indicator light
13. Start/Pause button with indicator light / Drain out
12
13
EN
1
