Startup

Switch the monitor ON and OFF

Connect the power cord to the monitor and the power source. Turn on the monitor using
the power button on the monitor or remote control. The power indication on the front
panel lights green. Press the power button again to turn off the monitor.

PC Connection

This CCTV monitor provides plug and play capability, meaning that the PC adjusts
automatically to the monitor's setting. The CCTV monitor sends configuration informa-
tion (EDID) to the PC using the Video Electronics Standard Association (VESA) Display
Data Channel (DDC) protocol.
PC Back
1. Connect the RGB Output of the PC to the VGA in jack on the set.
2. Turn on the PC and set.
3. Select the VGA input source with using INPUT button on the remote control.

Basic OSD setup

Turning on and off the CCTV monitor

1. Turn on monitor
8
Monitor Back
PC Audio Cable
VGA Cable
