Dust/Chip Extraction; Starting Operation - Bosch AdvancedCut 18 Originalbetriebsanleitung

LEDs on rechargeable battery
3 × continuous green light
2 × continuous green light
1 × continuous green light
1 × flashing green light
Recommendations for Optimal Handling of the
Battery
Protect the battery against moisture and water.
Only store the battery within a temperature range of −20 to
50 °C. Do not leave the battery in your car in the summer, for
example.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.
Selecting the saw blade
Only use saw blades that are suitable for the material you are going to cut. The saw blade should not be longer than required
for the cut you want to make.
Saw blade
NanoBlade Wood Basic
NanoBlade Wood Basic
NanoBlade Wood Speed
NanoBlade Wood Speed
Inserting the saw blade (see figure A)
Use only clean saw blades. Make sure that the saw
u
blade receptacle is free of chips and sawdust.
Use the locking lever (9) to open the cover (8) of the saw
blade receptacle. Insert the saw blade as shown in the fig-
ure. Make sure that the drive shaft and the end of the saw
blade fit in the recess on the saw blade receptacle (14).
Close the cover of the saw blade receptacle and lock it with
the locking lever. You should hear the locking lever click into
place.
The chain of the saw blade is tensioned automatically.
If the chain slips through or becomes detached from the
guide unit, open and close the cover (8) of the saw blade re-
ceptacle.
Removing the saw blade
Open the locking lever (9) fully open the cover (8) of the saw
blade receptacle. Remove the saw blade.

Dust/Chip Extraction

Dust from materials such as lead-containing coatings, some
wood types, minerals and metal can be harmful to one's
health. Touching or breathing-in the dust can cause allergic
reactions and/or lead to respiratory infections of the user or
bystanders.
Bosch Power Tools
State of charge Assembly
≈ 50–75 %
Remove the battery from the power tool before carry-
u
≈ 25–50 %
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
≈ 5–25 %
moved for transport and storage. There is risk of injury
≈ 0–5 %
from unintentionally pressing the on/off switch.
Inserting/changing the saw blade
When fitting or changing the saw blade, wear protect-
u
ive gloves. Blades are sharp and can become hot when
used for prolonged periods of time.
Avoid contact with the skin when changing a saw
u
blade and use protective gloves in perfect condition.
The saw blade can become hot when in operation for a
long time.
Do not pull on the chain and do not pull the chain off
u
the guide unit.
Always replace a complete saw blade with another complete
saw blade. The chain cannot be replaced on its own.
Cutting depth Order number
50 mm 2 609 256 D83
65 mm 2 609 256 F43
50 mm 2 609 256 D84
65 mm 2 609 256 D86
Certain dust, such as oak or beech dust, is considered carci-
nogenic, especially in connection with wood-treatment ad-
ditives (chromate, wood preservative). Materials containing
asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the ma-
terials to be worked.
Avoid dust accumulation at the workplace. Dust can
u
easily ignite.
Operation
Never bend the saw blade
u

Starting Operation

Switching on/off
To switch on the power tool, press the lock-off button (3) to
the left or right. Then press the on/off switch (4) and keep it
pressed.
Once the power tool is switched on, you can release the lock-
off button (3).
To switch off the power tool, release the on/off switch (4).
Materials
Wood, plastic (PVC, PC, PMMA)
Wood, plastic (PVC, PC, PMMA)
Wood, plastic (PVC, PC, PMMA)
Wood, plastic (PVC, PC, PMMA)
1 609 92A 8SB | (15.05.2023)
English | 15
