3.2 Montage

Assemble your SO3 2nd GEN/ SO3 PRO
1. Press the rear fender down and separate the hook from the fender buckle. Pull up the Frontbar until you hear a clicking sound indicating that the folding system has been locked in place. At
the same time the safety latch will also be locked in place.
4. Test the functionality of your SO3 2nd GEN/ SO3 PRO after the assembly.
Folding / Putting away your SO3 2nd GEN/ SO3 PRO
Before folding the SO3 2nd GEN/ SO3 PRO, make sure that it is powered off. Fold up the kickstand and hold the Frontbar while you pull out the right safety
pin. Rotate it in clockwise direction, then pull the lever. Proceed to fold down the Frontbar and fix it to the fender buckle using the hook. The SO3 2nd GEN/
SO3 PRO has been successfully folded once you hear a clicking sound.
Instructions on adjusting the dics brake
If the brakes are too tight, use a 4mm Allen wrench to loosen the screw of the pressure plate by turning anticlockwise. Shorten the length of the brake wire
to loosen the brakes, then tighten the screw again. If the brakes are too loose, loosen the screw and pull the brake wire to extend the wire, then tighten the
screw again.
copyright by www.soflow.com
2. Connect the cable between handlebar and frontbar.
3. Put the handlebar into the Frontbar and use the wrench to tighten the screw.
