Install the Camera

Notes on Camera Installation Position
• Install the camera 2-3 meters
(7-10ft) above the ground to
maximize the detection range of
the PIR motion sensor.
• For effective motion detection,
please install the camera
angularly.
NOTE: If a moving object approaches
the PIR sensor vertically, the camera
may fail to detect motion.
7 English
Mounting Height:
2-3 Meters
θ
PIR Detection Distance:
2-10 Meters
Mount the Camera to Wall
1 2
Rotate the base to separate Drill holes in accordance with the mounting
it from the bracket. template and screw the base of the bracket to
the wall. Next, attach the other part of the
bracket to the base.
NOTE: Use the drywall anchors included in the
package if needed.
English 8
