All manuals and user guides at all-guides.com Cargador universal de viaje por USB con adaptador de carge para el coche Universal USB-travel charger with USB-car charger Universal USB-Reiseladegerät mit USB-Autoladeadapter MEDION LIFE ® ® E69118 (MD 83053) Manual de instruccion Instruction manual Bedienungsanleitung...
All manuals and user guides at all-guides.com Contenido Uso apropiado ............2 Instrucciones de seguridad ........2 Manejar el aparato con seguridad ........4 Lista ................. 5 Fallos ................5 Volumen de suministro ........... 6 ...
All manuals and user guides at all-guides.com Uso apropiado Con este cargador de viaje pueden cargarse aparatos como, p. ej., reproductores MP3 o teléfonos móviles, a través de un puerto USB o uno de los adaptadores suministrados. La garantía no cubre el uso indebido. El adaptador de carga por USB para coche está...
Seite 4
All manuals and user guides at all-guides.com Conecte el aparato sólo a una toma de corriente (230 V ~ 50 Hz) bien accesible y cercana al lugar de emplazamiento. Para que el aparato pueda desconectarse rápidamente de la corriente, el enchufe debe permanecer accesible.
All manuals and user guides at all-guides.com fusibles deben ser cambiados siempre en un servicio técnico autorizado. Utilice el adaptador para coche sólo con una temperatura ambiente de entre 0°C y 40°C. Para cortar la alimentación eléctrica de su aparato, desconecte el cargador de viaje de la conexión de 12–24 de su vehículo o del enchufe de red.
All manuals and user guides at all-guides.com Lista Proteja el aparato contra golpes. Guarde el aparato en un lugar seco, protegido contra polvo y calor. No coloque objetos inflamables, explosivos o peligrosos cerca del aparato. Fallos En caso de haber desperfectos en el cable de carga, el adaptador de conexión o en el aparato, desenchúfelo inmediatamente.
All manuals and user guides at all-guides.com Volumen de suministro Compruebe que el suministro está completo, y, si no fuera éste el caso, avísenos dentro de un plazo de 14 días después de la compra. Con el producto adquirido ha recibido: ...
All manuals and user guides at all-guides.com Puesta en marcha con el adaptador para coche Enchufe el cargador para coche en la conexión de 12/24 de su vehículo. Dependiendo del cableado del vehículo, eventualmente haya que encender el vehículo para proveer de corriente la conexión de 12/24 V vehículo.
All manuals and user guides at all-guides.com Cambiar el fusible del adaptador de carga para el coche Desconecte el cargador para coche de la conexión de 12/24 V de su vehículo. Si fuera necesario, retire el cable USB. ...
All manuals and user guides at all-guides.com Inserción de la clavija de red Inserte la clavija de red que corresponda con la pestaña de soporte en la fuente de alimentación de modo que el rótulo „TOP“ de la clavija de red coincida con el rótulo „TOP“...
All manuals and user guides at all-guides.com Cuadro general de clavijas de adaptador Se suministran los siguientes adaptadores: Adaptadores Adaptador para Motorola Samsung Slim Samsung Sony Ericsson Series K + W Nokia Mini Nokia DC Mini Micro USB No se puede garantizar la compatibilidad con todos los aparatos de los fabricantes mencionados.
All manuals and user guides at all-guides.com Limpieza Por lo general, no resulta necesario limpiar el cargador de viaje. Procure que el cargador de viaje no se ensucie. No utilice disolventes, productos de limpieza cáusticos o aerosoles. Si resultara necesario, limpie la carcasa con un paño húmedo. Eliminación Aparato No tire bajo ningún concepto el aparato al final...
All manuals and user guides at all-guides.com Especificaciones técnicas Adaptador de red Modelo MD 83053 Tensión de entrada: AC 100-240V ~ 50/60Hz 0,18 A Tensión de salida: DC 5 V 1.0 A (USB) Adaptador para coches Fusible: T 2.5 Ah 250 V ...
Seite 14
All manuals and user guides at all-guides.com Content Correct use ............. 2 Safety information ..........2 Handling the appliance safely .......... 4 Setting up ............... 4 Faults ................4 Scope of delivery ............. 5 ...
All manuals and user guides at all-guides.com Correct use This travel charger is a charger for devices, such as MP3 players or mobile phones for example, that are recharged using a USB port or the included adapters. Liability is excluded for improper use. The USB car charger adapter is only suitable for use in vehi- cles with a 12 - 24 V connection, or the USB mains...
Seite 16
All manuals and user guides at all-guides.com cessible so that you can unplug the device from the mains quickly if necessary. Keep the travel charger away from moisture and avoid shocks, dust, heat and direct sunlight in order to pre- vent operational disruptions.
All manuals and user guides at all-guides.com Do not cover the travel charger in order to prevent non-permissible heating. Do not continue to use the travel charger if the housing or the supply lead to the device is damaged. Handling the appliance safely ...
All manuals and user guides at all-guides.com Scope of delivery Please check your purchase to ensure all items are included and contact us within 14 days of purchase if the delivery is incomplete: The following items are supplied with the product: ...
All manuals and user guides at all-guides.com Changing the fuse in the car charger adapter Remove the car charger adapter from the 12/24 V socket in your vehicle. Remove the USB cable if necessary. Open the fuse cover as shown. ...
All manuals and user guides at all-guides.com Inserting the mains plug Plug the required mains plug with the retaining tabs into the mains adapter so that the "TOP" caption on the mains plug corresponds to the "TOP" caption on the mains adapter.
All manuals and user guides at all-guides.com Adapter plug overview The following adapters are provided: Adapter Adapter for Motorola Samsung Slim SAMSUNG Sony Ericsson K+W Series Nokia Mini Nokia DC Mini Micro USB There is no guarantee of compatibility with all the makes referred to in this document.
All manuals and user guides at all-guides.com Cleaning Cleaning the travel charger is usually not required. Make sure that the travel charger is kept clean. Do not use solvents, corrosive or aerosol detergents to clean the prod- uct. If necessary, the casing can be wiped down with a damp cloth.
All manuals and user guides at all-guides.com Technical specifications Mains adapter Model: MD 83053 Rated input voltage: AC 100-240V ~ 50/60 Hz. 0.18A Rated output voltage: DC 5V 1.0 A (USB) Car adapter Fuse: T2.5 Ah 250V ...
Seite 24
All manuals and user guides at all-guides.com Inhalt Bestimmungsgemäßer Gebrauch ......2 Sicherheitshinweise ..........3 Sicher mit dem Gerät umgehen ........5 Aufstellung ..............5 Störungen ............... 5 Lieferumfang ............6 Inbetriebnahme über Autoadapter ......7 ...
All manuals and user guides at all-guides.com Bestimmungsgemäßer Gebrauch Dieses Reiseladegerät dient als Ladegerät für Geräte, wie z. B. MP3-Player oder Handys die über eine USB-Schnittstelle oder einem der mitgelieferten Adapter aufgeladen werden. Die Haftung bei nicht bestimmungsgemäßen Gebrauch ist ausgeschlossen.
All manuals and user guides at all-guides.com Sicherheitshinweise Bitte lesen Sie diese Anleitung aufmerksam durch und be- folgen Sie alle aufgeführten Hinweise. So gewährleisten Sie einen zuverlässigen Betrieb und eine lange Lebenserwar- tung Ihres Geräts. Halten Sie diese Bedienungsanleitung stets griffbereit und bewahren diese gut auf, um sie bei einer Veräußerung dem neuen Besitzer weitergeben zu können.
Seite 27
All manuals and user guides at all-guides.com auf die richtige Position. Durch die asymmetrische Form passt der Stecker nur in eine Position in die Buchse. Warten Sie nach einem Transport solange mit der Inbe- triebnahme, bis das Reiseladegerät die Umgebungstem- peratur angenommen hat.
All manuals and user guides at all-guides.com Sicher mit dem Gerät umgehen Bewahren Sie das Gerät außerhalb der Reichweite von Kindern und unbefugten Personen auf. Schützen Sie das Gerät vor Regen, Feuchtigkeit und Spritzwasser. Tauchen Sie das Gerät niemals in Flüssigkeiten. Aufstellung ...
All manuals and user guides at all-guides.com Lieferumfang Bitte überprüfen Sie die Vollständigkeit der Lieferung und benachrichtigen Sie uns innerhalb von 14 Tagen nach dem Kauf, falls die Lieferung nicht komplett ist. Mit dem von Ihnen erworbenen Produkt haben Sie erhal- ten: ...
All manuals and user guides at all-guides.com Inbetriebnahme über Autoadapter Stecken Sie den Autoladeadapter in den 12/24 V Anschluss Ihres Fahrzeuges. Je nach Verkabelung des Fahrzeuges ist es notwendig, die Zündung des Fahr- zeuges zu betätigen, damit der 12/24 V Anschluss des Fahrzeuges mit Strom versorgt wird.
All manuals and user guides at all-guides.com Inbetriebnahme über Netzstecker Schliessen Sie nun enweder ein USB Kabel oder das mitgelieferte USB Adapterkabel an den USB- Anschluss an. Stecken Sie den gewünschten Adapterstecker auf das Adapterkabel. Ziehen Sie den Autoladeadapter aus dem 12/24 V Anschluss Ihres Fahrzeuges, wenn der Autoladeadapter nicht verwendet wird.
All manuals and user guides at all-guides.com Einsetzen des Netzsteckers Stecken Sie den benötigten Netzstecker mit der Halte- nase so in das Netzteil, dass die Beschriftung „TOP“ auf dem Netzstecker mit der Beschriftung „TOP“ auf dem Netzteil übereinstimmt. Drücken Sie nun den Netzstecker an das Netzteil, bis er hörbar einrastet.
All manuals and user guides at all-guides.com Adaptersteckerübersicht Folgende Adapter werden mitgeliefert: Adapter Adapter für Motorola Samsung Slim Samsung Sony Ericsson K+W Serie Nokia Mini Nokia DC Mini Micro USB Die Kompatibilität zu allen Geräten der genannten Herstel- ler kann nicht garantiert werden.
All manuals and user guides at all-guides.com Reinigung Eine Reinigung des Reiseladegerätes ist in der Regel nicht notwendig. Achten Sie darauf, dass das Reiseladegerät nicht verunrei- nigt wird. Verwenden Sie keine Lösungsmittel, ätzende oder gasförmige Reinigungsmittel. Reinigen Sie das Gehäu- se ggf.
All manuals and user guides at all-guides.com Technische Daten Netzteil Modell MD 83053 Eingangsspannung AC 100-240V ~ 50/60 Hz 0.18 A Ausgangsspannung DC 5V 1.0 A (USB) Autoadapter Sicherung: T 2.5 A 250 V Modell MD 83406 Eingangsspannung DC 12 - 24V Ausgangsspannung DC 5.0 V 1.0 A (USB)
Seite 36
All manuals and user guides at all-guides.com Medion Service Center Visonic S.A. c/ Miguel Faraday, 6 Parque Empresarial "La Carpetania", N-IV Km. 13 28906 Getafe, Madrid España Hotline: 902196437 · Fax: 914604772 E-Mail: service-spain@medion.com www.medion.es...
