5.2 Fitting the grinding pins (Fig. 3, 4)
•
Unscrew the clamp nut (1).
•
Insert the appropriate clamp (2) and screw on
the clamp nut (1) by hand.
•
Insert the grinding pin (10) (make sure the
shaft diameter is correct!).
•
Make sure that the clamping length is at least
10 mm.
•
Tighten the clamp nut (1) using the two chuck
keys (15).
•
Check that the grinding pin is secure.
6. Operation
6.1 Connecting to a compressed air supply
•
Connect the nipple (6) to the quick-lock coup-
ling of a compressed air hose (the hose is not
supplied).
•
Note the maximum permissible operating
pressure of the equipment.
6.2 Switching on and off (Fig. 1)
Switching on: Push the safety lock-off (5) for-
wards, then press the operating switch (4) down.
Switching off : Let go of the operating switch (4)

6.3 Practical tips

•
Exert only moderate pressure on the work-
piece so that it can be machined at constant
speed.
•
Instead of accelerating your work, high pres-
sure will cause the drive unit to slow down
and even stop.
•
For your own safety, it is essential to secure
small workpieces with a screw clamp or vise.
•
Precision work/engraving: Hold the drive unit
like a pen (single-handed).
•
Rough work: Hold the drive unit like the hand-
le of a hammer (two-handed).
Anl_TC_PP_220_SPK9.indb 15 Anl_TC_PP_220_SPK9.indb 15
GB
7. Cleaning, maintenance and
ordering of spare parts
Disconnect the compressed air supply from the
equipment before performing any cleaning work.
7.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it down with compressed air at
low pressure.
•
We recommend cleaning the equipment im-
mediately each time after use.
•
Clean the equipment regularly with a damp
cloth and some soft soap. Do not use
cleaning agents or solvents; these may be ag-
gressive to the plastic parts in the equipment.
Ensure that no water can get into the interior
of the equipment.
7.2 Maintenance
Warning!
Disconnect the equipment from the compressed
air supply before you carry out any maintenance
or cleaning work.
Compliance with the maintenance instructions lis-
ted here will help this quality product provide you
with a long service life and trouble-free operation.
Regular lubrication is essential for your equip-
ment to work properly for a prolonged period of
time.
Regularly check the speed and the vibration level
by simply observing the tool.
Note: Use environmentally friendly compressed
air oil if you want to operate the equipment out-
side the workshop.
The following lubrication options are available:
Lubrication by mist oiler
Connect a mist oiler between the compressed air
source and the equipment (not supplied, available
at retail stores)
- 15 -
