We appreciate the trust you have placed in JBC by purchasing this equipment. It
has been manufactured with the strictest quality standards in order to give you the
best possible service.
Before using this equipment, we recommend you read these instructions carefully.
Electric desoldering pump
MS 9004 Ref.9004000
Aspiration inlet
The MS 9004 is a suction pump that includes a
vacuum pump that only needs to be connected
to the control unit.
You can connect the following stations from the
Advanced range: DD 5700, DM 6700 and the
MS 9000.
Connection
Spare filters
Ref.0966689
Ref.0780637
Technical specifications
- Supply: 24V.
- Power: 10W.
- Weight of complete unit: 1,6 Kgs.
- ESD protected housing.
Typical surface resistance: 10
square.
- Complies with CE standards on electrical
safety, electromagnetic compatibility and
antistatic protection.
This product should not be thrown in the
garbadge.
Changing the pump inlet filter
- Disconnect the desoldering iron tube and
unscrew the stopper.
- Take out the 2 paper filters, throw away
those which are soiled and replace them
with new ones. Always use 2 filters.
- Screw on the stopper and connect up the
tube.
- Check the airtightness.
JBC reserves the right to make technical changes without prior
notification.
1

ENGLISH

5 11
-10 Ohms/
