Supplement to the Operating Instructions for
Back pressure regulators UV 5.1 ATEX H2

4 Applied standards and directives

The indicated product is designed according to the AD 2000 regulations without the data sheets S1 and S2.

5 Safety instructions

5.1 General precaution

The same safety regulations apply to a fitting as to the system into which it is installed. These instructions only
give those safety recommendations that have to be additionally observed for the fitting.

5.2 Special safety instructions for the plant operator

The following requirements for the intended use of a fitting are not the responsibility of the manufacturer but
have to be guaranteed by the user:
» The fitting may only be employed for the purpose described in section Intended use [} 6].
» Only competent specialist personnel may install, operate and service the fitting. Competent as defined in
these instructions refers to persons who, because of their training, specialist knowledge and professional
experience, are capable of correctly assessing and properly executing the work with which they are
entrusted and of recognizing and rectifying hazards.
» The pipeline system must be properly designed and installed so that the fitting can be mounted and
operated without any tension.
» The fitting must be properly installed in the correct mounting position.
» The recommended installation, as described in the relevant MANKENBERG data sheet, must be used for
the pipeline section into which the pressure-regulating valve is installed. All control and/or leakage lines that
are required on the pressure-regulating valve must be laid properly, in accordance with the accompanying
MANKENBERG data sheet.
» A pressure-regulating valve with an open spring must be installed in such a way that it presents no risk of
crushing to the oerating personnel.
» The usual flow rates should not be exceeded in the pipeline section during continuous operation, and
abnormal operating conditions such as vibrations, unusually high flow rates, etc. should be avoided or – if
unavoidable – clarified with the manufacturer in advance.
» The prevailing operating conditions must comply with the limits of the design data stated in the
MANKENBERG order confirmation.
» The corrosion protection for the fitting must be adapted to the local environmental conditions.
» The fitting must not be coated with thermal insulation.
Detailed notes are provided on some of these prerequisites in the following sections.
