Camera setup

Accessing the setup menu

The setup menu can be accessed and controlled either by using the USB
connector or by using the RS-422 interface.
To access the setup menu please install the „Camera Controller GUI" soft-
ware from the enclosed CD-ROM. During the installation, you will be promp-
ted to install Silicon Laboratories drivers. This portion of the installation is
necessary for using a USB connection to the camera.
Make sure that the camera is properly connected to the PC before running
the GUI.
Please select „LWIR" mode. When the GUI first opens, it will display "Not
Connected" on the bottom left.
Connect to the camera by selecting „Tools" and then „Connection".
28
