SYSTEM SETTINGS (Settings)
Select Settings and confirm.
This will take you to the submenu for accessing the system information (see table):
Settings
Operational status
DMX Fail =
with DMX signal fault
Dimmer
= Dimmer Curve
Curve
Constant brightness
Constant
when fading from
Bright- =
cold white to warm
ness
white and vice versa
Dimmer
= Dimmer response
Response
PWM Configuration of
=
Frequency PWM frequency
18
Hold Last command is retained
User Colour 1 Activates User Color 1
Fade out 10s 10 seconds fade to blackout
Blackout Activates blackout
Full On All LEDs 100% output
Light intensity increases linearly
Linear
with DMX value
Light intensity can be finely adjust-
Exponential ed at lower DMX values and broadly
adjusted at higher DMX values
Light intensity can be broadly
adjusted at lower DMX values
Logarithmic
and finely adjusted at higher DMX
values
Light intensity can be finely adjust-
ed at lower and higher DMX values
S-curve
and broadly adjusted at medium
DMX values
Off Function disabled
On Function enabled
LED Light responds abruptly to changes
in DMX value
Light behaves like a halogen spot-
Halogen
light with slight brightness changes
800 Hz / 1200 Hz /
2000 Hz / 3600 Hz /
12 kHz / 25 kHz
