Installation Guide
Floppy
- 1 floppy port
- Supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 VGA port (optional, for G965 only)
- 1 serial port (COM1)
- 1 parallel port supporting SPP/EPP/ECP mode
- 4 USB 2.0 Ports
- 1 LAN jack (10/100/1000)
- 6 flexible audio jacks
- 1 1394 port (optional)
On-Board Pinheaders
- 3 USB 2.0 pinheaders
- 1 1394 pinheader (optional)
- 1 S/PDIF pinheader (optional)
- 1 Front Audio pinheader
- 1 IrDA pinheader
- 1 Chassis intrusion pinheader
- 1 CD-in connector
Slots
- 1 PCI Express x16 slot
- 1 PCI Express x1 slot
- 1 PCI Express x4 slot
- 2 PCI slots
- Support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.5cm X 22.5cm)
M ounting
- 6 mounting holes
En-3
