10.
. Protection
. Ambient temperature
. Cooling
. Mounting into a 19" rack
. Dimensions
- as table model
- when rack-mounted
(without feet, but with
mounting brackets)
Weight
: Primarily with fuses VL, and VL.
10 A medium delayed-action for
220 V and 235 V
20 A medium delayed-action for
110 V and 125 V.
: Minimum 0%, maximum 35°C.
: The apparatus is cooled by natural
air circulation through the perfora-
ted top and bottom plate.
The air circulation must not be
obstructed.
: The apparatus is suitable for moun-
ting in a 19" rack.
. To this end, proceed as follows:
- Remove side plates and top plate
(See under point A of chapter ID.
= Remove feets and bottom plate.
- Replace plastic clamping plates A
(see fig. 4) by clamps provided
on delivery.
: Height 147 mm
Width 442 mm
Depth 400mm
: Height 133 mm
Width 482 mm
Depth 400 mm
: Net. 28 kg.
