10.2.4
Connection Object
Class Code: 5
Anzahl der Instanzen: 3
1 Instanz-Attribute (Explicit Message Connection)
Attribute
ID
1
2
3
4
5
6
7
8
9
12
13
14
15
16
17
Zumutbare Änderungen aufgrund technischer Verbesserungen vorbehalten.
Pepperl+Fuchs GmbH · 68301 Mannheim · Telefon (06 21) 7 76-11 11 · Telefax (06 21) 7 76 27-11 11 · Internet http://www.pepperl-fuchs.com
Wenn die polled I/O Message Connection den etablished state (3)
verläßt, werden die AS-i-Ausgangsdaten gelöscht.
Access
Name
Rule
Get
State
Get
Instance Type
Get
Transport Class Trigger
Get
Produced Connection ID
Get
Consumed Connection ID
Get
Initial Comm. Characteristics
Get
Produced Connection Size
Get
Consumed Connection Size
Get/Set Expected Packet Rate
Get
Watchdog Timeout Action
Get
Produced Connection Path
Length
Get
Produced Connection Path
Get
Consumed Connection Path
Length
Get
Consumed Connection Path
Get
Production Inhibit Time
AS-i DeviceNet-Gateway
DeviceNet-Schnittstelle
DeviceNet-
Data Value
Data Type
USINT
1 = configuring
2 = waiting for connec-
tion ID
3 = estabilshed
4 = timed out
5 = deferred delete
USINT
0 = explicit message
USINT
83 (hex.)
UINT
10xxxxxx011 (binär)
xxxxxx=Node Address
UINT
10xxxxxx100 (binär)
xxxxxx=Node Address
USINT
21 (hex.)
UINT
204 (dez.)
UINT
204 (dez.)
UINT
0 (ms)
USINT
0 = timeout
1 = auto delete
2 = auto reset
3 = deferred delete
USINT
0
null (keine Daten)
USINT
0
null (keine Daten)
UINT
