EN
• The pH of water must between 6.5 and 8.5.
• The temperature of the liquid conveyed may not
exceed 35 °C.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Connecting to the power supply
Check that the power supply and plug used in
accordance with your machine. Have a look at the
rating plate on the machine. Any changes should
always be carried out by a qualified electrician.
Warning! This machine must be earthed. If
not properly earthed this machine can cause
an electrical shock. Be sure that the power
supply outlet is earthed. If there is any doubt,
have it checked by a qualified electrician.
Warning! Avoid contact with the terminals
on the plug when installing (removing) the
plug to (from) the power supply outlet.
Contact will cause a severe electrical shock.
Replacing cables or plugs
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard. Imme-
diately throw away old cables or plugs when they
have been replaced by new ones. It is dangerous to
insert the plug of a loose cable in the wall outlet.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm². When using a cable reel
always unwind the reel completely.

2. MACHINE INFORMATION

The rain barrel pump is intended for private use
for irrigation of gardens, it is not intended for
commercial use. Explosive, corrosive, flammable
6
substances, sewage, salt water, grease and oil
must not be conveyed by the pump.
It is solely intended for pumping clear and rain
water. The particle sizes of the solids in the water
must not exceed the maximum particle size speci-
fied in the technical data.
This pump is not designed for continuous operation
(e.g. as a swimming pool or pond circulation pump)
or for stationary installations (e.g. lifting device,
fountain pump).
Model No.
Application
Floating switch
Voltage
Input power
Protection class
Max. flow rate
Max. pressure
Max. pumping height
Max. depth
Max. particle size
Min. residual water height
(manual operation) *
Switch-on height (automatic
operation)
Switch-off height (automatic
operation)
Max. water temperature
Protection
Built-in thermal motor pro-
tector
Cable length
Weight
* The stated residual water height is only achieved
in manual operation.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
SP509AC
Clean water
Yes
230 VAC / 50Hz
400W
Class I
5200l/h
1.1 bar
11m
7m
5mm
50mm
50cm
5cm
35°C
IPX8
Yes
10m
4.22 kg
