8.7 Bauelemente des Antriebsystems
Pos.
Name
01
Gear shaft
02
gear
03
gear
04
Sliding gear
05
Sliding gear
06
gear
07
gear
08
Sliding gear
09
Sliding gear
10
Cross screw
11
Cross nut
12
Angle gear
13
Angle gear
14
Elevating screw
15
Elevating nut
16
Sliding gear
17
Sliding gear
18
gear
19
gear
20
gear
21
Sliding gear
22
Angle gear
22a
cluth
23
Angle gear
24
Longitudinal
screw
50
gear
51
gear
52
gear
53
Bevel gear
54
Bevel gear
UWF 5
Anzahl
Art.-Nr.
1
05206
1
06204
1
06205
1
06202
1
06201
1
06217
1
06218
1
06224
1
06223
1
02231
1
52K713
1
02210
1
02207
1
02226
1
02304
1
06207
1
06208
1
06221
1
06219
1
06220
1
06222
1
03204
1
03233A
1
03201
1
1
X5005207
1
X5005202
1
X5005201
1
X643606204
1
X643606205
BETRIEBSANLEITUNG
Pos.
Name
25
Longitudinal nut
26
Longitudinal nut
27
Angle gear
28
Angle gear
29
gear
30
gear
31
gear
32
gear
33
gear
34
Sliding gear
35
gear
36
Timing pulley
37
Timing gear belt
38
Timing pulley
39
gear
40
gear
41
gear
42
Gear shaft
43
Gear shaft
44
gear
45
gear
46
gear
47
gear
48
gear
49
gear
55
Bevel gear
56
Bevel gear
57
Gear shaft
58
gear
Anzahl
Art.-Nr.
1
03301
1
03302
1
613203209
1
03223
1
02224
1
02246
1
02213
1
02214
1
02218
1
02216
1
02215
1
02235
1
1
02239
1
02232
1
02238
1
X5005215
1
643205203
1
X5005216
1
X5005214
1
X5005212
1
X5005210
1
X5005211
1
X5005209
1
X5005208
1
X643606209
1
X643606208
1
X5005206
1
X5005205
Seite 25 von 41
