5. Mount the bleaching head by turning clock-
wise the conical fixator located on the tel-
escopic arm. By turning the conical fixator
located on the straight arm, the telescopic
arm is firmly fixed.
6. Connect the cable from the top of the angu-
lar arm to the one coming from the bleach-
ing head using the connectors (see figure).
Note: the device will not work if the cable
connectors are incorrectly coupled.
7. Connect the cable on the bottom of the an-
gular are with the power adapter using the
connectors (see figure). Note: the device
will not work if the cable connectors are in-
correctly coupled.
8. Plug the power cord into the power network, SHUKO socket.
