VII. PREPARATION FOR OPERATION
1. BLANCONE ARCUS
®
patient and the dental unit. See the positioning examples (Section X).
The bleaching head must be in the same vertical plane and parallel with the arc of the teeth with a
distance between 5-15 cm. See the positioning examples (Section X).
2. Plug the power adapter into the power network. Only one point/dot on the display
lights up. Press START / STOP button and then the "Hi" (High) or "Lo" (Low) inten-
sity indication appears.
3. The display shows "HI" - a high intensity level. If you want to switch to the "Lo" (Low)
intensity mode, press the TIMER / MODE (+ / -) button once. Then the display will
show "Lo". Every time before setting the required time, you will be able to select the
Hi or Lo intensity level.
4. Press the START / STOP button once again and set time option will be displayed.
Note that the device will save the time frame used in the latest bleaching procedure.
Required timeframe for operation is set by pressing TIMER + (increasing time) and
TIMER- (reducing time):
The display on the bleaching head will indicate timeframes between 10 sec. and 9
min. and 50 sec. with a dot between the two digits.
Examples:
Display indicates: 13. This means the timeframe is set to 13 min.
Display indicates: 0.1. This means the timeframe is set to 10 sec.
Display indicates: 9.5. This means the timeframe is set to 9 min. and 50 sec.
The display on the bleaching head will indicate timeframes between 10 min. and 30
min. without a dot between the two digits.
5. Press the START / STOP button one final time and the device will start to emit light. A flashing dot on the
display will indicate that the device is working properly.
6. If either of the TIMER / MODE (+ / -) buttons is pressed dur-
ing operation, the unit switches to Pause mode. A blinking
display with the remaining time will indicate that the device
is paused. Operation is resumed by pressing any TIMER /
MODE (+ / -) button again.
7.
To Stop the bleaching device at any time press the START
/ STOP button. If the device is not manually stopped it will
stop after the selected time has elapsed. Note that the fan will continue to work for some time in order
to cool down the unit.
8. At the end of the day turn off the device by holding down
the Start / Stop button for 3-4 seconds or by disconnecting it from the power network.
12
