V. PACKAGING / COMPONENTS
1. Power cord 24 V DC
to the Bleaching Head
2. Straight arm
3. Telescopic arm
4. Central position
locking mechanism
5. Angular Arm
6. Fixing bracket
7.
Bleaching head
positioning mechanism
8. Bleaching head
9. Dental unit vertical arm
10.
Control panel
10A. "+" Timer or "Pause" button
10B. "-" Timer or "Pause" button
10C. Start / Stop button
10D. Display
11. Cable retaining clip
12. Cables and connectors
13. Safety glasses - 2 pcs.
14. Power Adapter
100-240V AC / 24V DC.
Fine positioning is done by turning the Bleaching head so that the light is perpendicular to the pa-
tient's teeth and centered on them.
If the movement of the Bleaching head is difficult or it does not hold the selected position it is necessary
to adjust the Bleaching head positioning (7) and Telescopic fixator locking mechanism (4).
ULTRA
DUETTO
HOME
NIGHT
DUETTO
ACTIVE
CLICK
ARCUS
LIPS
ARCUS
DUETTO
CARE
3 4
7
8
1
10
D
B A C
14
Dental LED bleaching activation unit - FIXED
2 11
5
6
12
13
9
