VI. INSTALLATION
BLANCONE ARCUS
®
of the dental unit.
1. Unpack the transport box, remove the
components and initially assemble the
fixing bracket to the dental unit. Make
sure the diameter of the bracket match-
es the diameter of the dental unit vertical
arm. Soft PVC tape strips are provided in
the case that there is a need to compen-
sate for small difference in the two diame-
ters. Tighten the two screws with a 4 mm
Allen key (included in the package).
2. Tighten the stop/safety screw with a 3
mm Allen key (included in the package).
3. Insert the cable through the small open-
ing of the fixing bracket and place the two
arms.
4. By tightening the fixator (by turning) the
straight arm can move down and up for po-
sitioning.
10
Dental LED bleaching activation unit - FIXED
BUILT-IN is designed to be mounted with a fixing bracket to the vertical arm
+
