Awnings
Hang the middle roof pole in the
threaded fixing eye or Vario Clip
on the caravan and connect this to
the centre bracket. Put up the centre
bracket and determine the centre
height.
While setting up, we recommend that all
brackets are secured with a guy-rope to
avoid gusts of wind picking up the roof of
the awning with its frame.
Put up one side bracket.
Hang the side roof pole in the
threaded fixing eye or Vario Clip on
the caravan and connect it to the side
bracket. Spread the pole slightly and
then tighten the screws completely.
Connect this side bracket with the
centre bracket, spread the poles apart
slightly and then tighten the screws
completely.
