Technical data
Drive system 87000 / Controler DYH-020 - Montevo Home (V1.0)
Control and motor system:
Adjustment mechanism:
Synchronization:
Tube diameter of the lift columns:
Temperature range at point of use: 0°C to + 30°C
Max. relative humidity:
Rated voltage:
Rated frequency:
Intermittent periodic duty:
Maximum load:
Protection class:
Maximum power consumption
during lifting operation:
Power consumption in
standby mode:
Traversing speed:
Maximum adjustment range:
Control panel up / down:
Operating panel with
memory function:
Noise emission:
Rating plates are located on the control system housing,
the lift columns and underneath the desktop.
Veyhl GmbH
Spindle adjustment in the leg
electr. synch. by electr. control unit
70 mm / 65 mm / 60 mm (outside / middle / inside)
85 % (not condensing)
120 - 240 V ~
50-60 Hz
max. 1 min / 12 min
80 kg
IP 20
2 lift columns 350 W
< 0.1 W
50 mm/s (without load)
650 mm
Standard
Optional (wired)
< 42 dB(A)
M O N T E V O H O M E I N S T R U C T I O N S H E E T
