Operating Instructions - VEVOR VS5500 Handbuch

I. Making a bag with bag roll
1. Plug the unit into a power source;
2. Open the top cover.
3.Make sure the bag cutter is on one end of the
cutter rack, Then put the cutter rack to the back–
Fig.1
4. Pull out the bag material to the suitable
length you want– Fig.2
5.Put down the cutter rack and make sure it is on the
right place of the bags, then slide the cutter from
one end to the other end to cut the bag– Fig.3
6. Put one end of the bag on top of the sealing
strip, but not enter the vacuum chamber– Fig.4
7. Close the upper lid and press tightly till you
hear it click in place on both sides– Fig.5
9. Press Manual Seal button to start sealing the
bags -Fig.6
10.Press the release button to open the cover
and take the bag out of the machine. the bag is
then done and is ready for vacuum sealing -Fig.7
II. Vacuum packaging with a bag
1.Put the items inside the bag. Use only the
special designed vacuum bags supplied by
us with vacuum channels.
2. Clean and straighten the open end of
the bag, make sure no dust, wrinkle or ripples.
3. Place the open end of the bag within the
vacuum chamber area. Make sure the air intake
is not covered by the bag. – Fig. 1

OPERATING INSTRUCTIONS

07
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.1
Fig.2
Fig.3
