CPVan CP5 Installationsanleitung Seite 5

Installing Your Panic Button
- Wearable SOS Necklace for children and elder people.
Adding Your Panic Button into CP5 panel
- From the Home Screen, press Then Input the Main user password "0808" Press
- Scroll to " 5.Device Set", Press , Select " 1.Zone ", Press
Press , Select " 1.By Code Learn", Press
&etc), it's total in 32 Wireless zones. Select any zone, Let's Select "WL, Zone 3" as example.
Press to "WL, Zone 3" icon, Press
shows " Registered!", Press to "Change the name" Press
Finally, Press .
For Reference.
Be Noticed that the "WL, Zone 3" should be "ON" with Bypass Zone.
Questions? Contact us at E-Mail info@cpvans.com
, Select " 1.WL.Register ",
, it shows"WL.Zone1, WL.Zone 2, WL Zone 3
, Then Press the panic button within 60s, it will
to edit the name at your side.
-06-
Test Your Panic Button
Back to Home Screen, Press , Then press your panic button, The CP5 panel will alarm and
showing " Panic button Untreated". Press
should be" 08080".
Installing Your Water Leaks
Location
- Water Leaks can affect many areas of a home. crawl spaces, basements, bathrooms
kitchens, laundry rooms. We recommend having at least one Water Sensor at the lowest point
in your home.
Installation
- At your location, at the lowest point of its floor (where water would pool) measure from the
floor approx. 12 in (or so when the sensor is on the wall, the knob on the bottom rests on the
floor). Pull the battery tab.
- Apply the 3M tape & hang so the metal part on the bottom rests On the floor.
Adding Your Water Leaks into CP5 panel
From the Home Screen, press Then Input the Main user password "0808" Press
-- Scroll to " 5.Device Set", Press , Select " 1.Zone", Press
Press , Select " 1.By Code Learn", Press
Questions? Contact us at E-Mail info@cpvans.com
and input your "Master Code+0", the default
, Select "1.WL.Register",
, it shows" WL.Zone1, WL.Zone 2, WL Zone
-07-
