Change your password:
- Your Panel has two passwords, one (Master Code) is used to disarm the system, the other
(Installer Code) is used to access & make changes in the Programming Menu.
- The Default Master Password to disarm the system is "0808"
- The Default Installer Password to access & make changes to the Programming menu is "1234"
Arm/Dis.LED
- Enter the Master password, press Then Input the Master password "0808" Press
- Scroll to "Code Set", press it shows " 1 Master Code", press twice
digital password, press When "Revised", press
need Lock to requires a password to disarm your system, Return to the Home Screen by
pressing two times.
Test your news passwords
From the Home Screen, "Arm"your system by pressing
by typing in your "Master" password, then press
- typing your password again, you should be in back in the Programming Menu. Enter your
Installer Passwords with Default "1234".
Adding Phone Numbers
- Press enter your 4-digits User password you wrote down,then press
option "4.Phone Set", and then press
you want to add ( Ex: 666-123-4567, you may need to type "1" before the area code). there are
four(4) groups phone number you can add.
Questions? Contact us at E-Mail info@cpvans.com
to write 4
two times to change the name. Keypad
once armed,"Disarm" your system
Select
five times. Now you can enter a phone number which
-02-
Install Your CP5 Panel
Your Panel comes with four screws and plastic wall plug, two for spare.
Pick a discreet location near a power outlet & stick "Installing Hole Drawing". Drive 2 screws
on the fixed position , Hang the control panel directly on the screws. While driving the screws,
be aware of the depth of screws to make sure easy hang and tamper switch work normally.
It's Rear tamper in back panel. Compress the tamper switch while installing. If your panel is
removed or opened, tamper will be triggered.
Installing Hole Drawing
Wall
Installing Your Wireless Door/Window Contacts
Clean Surfaces
- Once you have planned where you will put your Contact Sensors (refer to image below for
recommended placement) it's need to clean the surface you will be sticking the Contact to.
Use your preferred cleaning solution & allow the surface to dry.
Installation
- The adhesive tape is already apply to the back side of each the Contact & Magnet. Peel
one side of the protective paper off of each shape & Remove the battery tab from the contact.
Questions? Contact us at E-Mail info@cpvans.com
-03-
