The SUEVIA EASYCLEANER MINI is ready for use as soon as it is mounted on a solid wall and the electrical connection is
established (an emergency shut-off switch and a residual current device are to be provided on site (see electrical circuit
diagram).
By vibration the brush, the EASYCLEANER MINI is starting up. Now the brush are rotating. Fixed operating time: 2 min.
Resistance reverse mechanism adjustable. In case of an overload situation, e.g. wound up tail, the EASYCLEANER MINI
stops automatically and changes direction of rotation. After a short phase of making acquaintance, the EASYCLEANER
MINI is readily accepted by the animals.
SUEVIA EASYCLEANER MINI is equipped with a security automatic shut-off. This automatic shut-off possibility stops
the rotating brushes and starts turning them in the opposite direction as soon as the adjusted force is
exceeded. (Factory-adjusted is an average force of 4 A).
4x to drill
08.2022 · Technische Änderungen vorbehalten · Technical data can be changed without prior notice · Des changements techniques reservés · Мы оставляем за собой право на технические изменения и
дополнения, а также возможные опечатки. · 104.8171

Functional Principle

Hole pattern for drilling
14 cm
Ground
35 cm
2 cm
12 cm
