| VALVES AND JUMPERS
A large variety of valves can be installed
allowing for greater versatility. You can refer
to the table below to check the jumper
layout for the compatible model of valves.
TYPE OF VALVE
E88CC
6N6P
6N1
6922
6H30P
6H6N
E83CC
E82CC
E81CC
12AX7
12AU7
12AT7
6N2P
6N6P
6H30P
6H6N
6N1P
E82CC
12AU7
2
Please refer to your dealer to install the
valves into your TUBE to avoid a breach of
warranty.
JUMPER
W1 pin 1,2
W2 pin 1,2
W3 pin 1,2
W4 pin 1,2
W1 pin 2,3
W2 pin 2,3
W3 pin 2,3
W4 pin 2,3
W1 pin 1,2
W2 pin 1,2
J3 pin 2,3
J4 pin 1,2
J5 pin 2,3
J6 pin 1,2
J3 pin 1,2
J4 pin 2,3
J5 pin 1,2
J6 pin 2,3
