Rotating the roller wheel up or down during charging will switch the information displayed on the lower half of the LCD screen
between cell voltage, cell internal resistance (IR) and working parameters. Cell voltage and IR can only be displayed during
the balance charging process.
Dual independent output channels, setting and work independently as follows: Channel 1 charging, Channel 2 stand-by.
The colour LCD display clearly shows the working status of both two channels in real time.
CH1 Charging (Violet colour)
CH2 Discharging (Yellow colour)
SYSTEM SETTINGS MENU
Long press the roller wheel to activate the System Setting menu.
Language
Select the language of the menu
MIN Input Voltage
Adjustable 10-12 V to protect the car battery
Power Distribution Adjust the power available to CH1 and CH2 in the AC mode.
Capacity Cut
Terminates the charge process once the pre-set capacity value is reached
Time Cut
Terminates the charge process once the pre-set time value is reached
Temperature Cut
Terminates the charge process once the pre-set temperature value is reached (requires the optional
temperature sensor)
Backlight
Intensity of the display backlight - High, Medium, Low
Volume
Buzzer volume - High, Medium, Low, Off
About
Software and hardware version information
Factory Reset
Returns all settings to factory default values
Back
Return to the last program or menu
Volume: OFF - the keypad/wheel sounds are off, the error sounds remain active.
CH1 Charging Completed (Green colour)
CH2 Discharge...Complete (Red colour)
6
