Energetics ET 12.0 Bedienungsanleitung Seite 6

Part list – ET 12.0 Ergometer - 2007
NO. DESCRIPTION
1 BASE FRAME
2 UPRIGHT TUBE WELDMENT
3 FIX HANDLEBAR
4 HANDLE BAR (L)
5 HANDLE BAR (R)
6 LOWER SWIVEL HANDLE BAR
7 SWIVEL TUBE
8 PEDAL TUBE WELDMENT (L)
9 PEDAL TUBE WELDMENT (R)
10 FRONT&REAR STABILIZER
11 TURNING PEDAL DISC TUBE
12 AXLE FOR PULLEY
13 BUSH FOR AXLE
14 AXLE SUPPORT
15 BUSH FOR LOWER H.B
16 SCREW
17 SCREW
18 SCREW
19 SCREW (NYLON)
20 SCREW
21 ALLEN HEAD BOLT
22 ALLEN HEAD BOLT
23 SCREW
24 SCREW
25 SCREW
26 HEXAGON NUT
27 NYLON NUT
28 WASHER
29 WASHER
30 WASHER CURVE
31 SPRING WASHER
32 BEARING
33 CLIP
34 END CAP
35 FRONT STABILIZER COVER(L)
36 FRONT STABILIZER COVER(R)
37 REAR STABILIZER COVER
38 KNOB
39 PEDAL (L)
40 PEDAL (R)
41 HANDLEBAR END CAP
42 FIX HANDLEBAR END CAP
SIZE Q'TY NO.
1 43
1 44
1 45
1 46
1 47
2 48
2 49
1 50
1 51
2 52
2 53
1 54
1 55
1 56
2 57
M8x15 mm 10 58
#8-32 UNC 2 59
M8x50mm 4 60
M8x20mm 2 61
M8x90mm 2 62
M8x53mm 4 63
M6x14mm 5 64
M4x10mm 2 65
M5x16mm 16 66
M5x30mm 8 67
M8 4 68
M8 3 69
M8x 38 4 70
M8x 16 15 71
M8 4 72
M8 6 73
<6004ZZ> 2 74
C20 2 75
1 76
1 77
1 78
2 79
2 80
1 81
1 82
2 83
2 84
6
DESCRIPTION
PLASTIC CAP
CHAIN COVER (L)
CHAIN COVER (R)
TURNING PEDAL DISC
DECORATE COVER
PLUG AXLE SUPPORT
PLASTIC INSERT
OVAL CAP
BELT
SET SCREW
FIX HANDLEBAR FOAM GRIPS
HANDLEBAR FOAM GRIPS
FIX HANDLEBAR FOAM GRIPS
BUSHING
PEDAL KNOB
SCREW
WASHER
SENSOR BRACKET
MAGNET
SCREW
CONTROL BOARD
COMPUTER
ADAPTOR
PULSE GRIP UNIT
PULSE WIRE
COMPUTER CABLE (UPPER)
SERVO MOTOR &COMPUTER
CABLE (LOWER)
SENSOR WIRE
FLYWHEEL
SCREW
DC CABLE
TURNING PLATE COVER
IDLE WHEEL BRACKET
BRACKET OF SPRING
IDLE WHEEL
SCREW
WASHER
NYLON WASHER
CLIP
BEARING
SPRING (BIG)
WIRE OF FLYWHEEL
SIZE Q'TY
8
1
1
2
1
14
2
2
1
M10x28mm 4
1
2
2
2
4
#6x12mm 1
DIA. 20 2
1
1
M5x12mm 2
1
1
1
2
1
1
1
1
1
M4x16mm 2
1
2
1
1
1
M8x25mm 1
M6 4
M10 2
C12 1
<6001ZZ> 1
1
1
