9.4.3.1 Viewing and editing the mowing plan
With this function you can set when the robotic lawn-
mower should start mowing and how long it should
mow for each individual day.
There is one start time per day (later max. two start
times) available.
In this function you can also set the days on which
the lawn edges are to be mown.
m ATTENTION
Changing the mowing schedule, starting a mow-
ing operation, switching the automatic on and
off, sending the robotic lawnmower home and
changing the date and time may result in activ-
ities that are not expected by other people. Af-
fected persons must therefore always be in-
formed in advance about possible activities of
the robotic lawnmower.
9.4.3.2 Adjusting the mowing zones
In this function you can manually set up two differ-
ent mowing zones in %. By default, the function is
set to "AutoMultizone". Here, the mower starts after
each charging process at an arbitrary place along
the boundary wire.
This means:
After the first charging process, the robotic lawn-
mower moves along the boundary wire in accord-
ance with the set % number for zone 1 and starts
mowing.
After the second charging process, it does the same
in accordance with the set % number for zone 2, etc.
Example:
You have installed 200 m of boundary wire and set a
value of 25% for zone 1.
After charging, the robotic lawnmower drives 50 m
along the boundary wire and starts mowing from
there.
m NOTE
This function allows you to start the robotic lawn-
mower in difficult-to-reach passages, for example, to
ensure a perfect mowing pattern.

10. Cleaning

m ATTENTION
Switch off the product with the
ing.
m ATTENTION
Put on protective gloves before cleaning the rotating
blade carrier.
We recommend that you clean the product directly
after every use.
-button before clean-
Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can
penetrate the product interior.

11. Transport

• Press the button ("POWER ON/OFF" button) to
switch the robotic lawnmower (1) off.
• Wear protective gloves when transporting the ro-
botic lawnmower (1).
• Carry the robotic lawnmower (1) securely with both
hands.
To prevent damage, avoid the robotic lawnmower (1)
falling to the ground from greater heights.
If this does happen, it must be immediately taken to a
specialist workshop for inspection.
Do not continue to use the robotic lawnmower (1) be-
fore this has been done.

12. Storage/Hibernation

Your mower will give you pleasure for longer if it is
allowed to hibernate.
Although this is not a problem, we recommend that
you store your mower in a closed room, e.g. in the
garage, during the winter.
Before storing the mower:
• Clean it thoroughly (see point 10)
• Charge the rechargeable battery fully.
• Switch the product off.
• Remove the rechargeable battery (see point 13.2).
Store the product and its accessories in a dark, dry
and frost-free place that is inaccessible to children.
The optimum storage temperature lies between 5 and
40 ˚C.
Store the robotic lawnmower (1) in its original pack-
aging.
Cover the robotic lawnmower (1) to protect it from
dust and moisture.
Store the operating manual with the robotic lawn-
mower (1).

13. Maintenance / Update

m ATTENTION
Disconnect the mains plug before carrying out any
maintenance work.
Connections and repairs
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
GB | 33
