1.
If needed screw protection covers for profibus connections to M12
connectors.
2.
Put the cover back in place and fasten with the 4 screws.
3 Connection
Pin Assignment Connector
Recommended mating connectors:
Phoenix Contact
SACC-M12MSB-5CON-PG9 SH AU –
1507764000
Recommended cable dimensions:
Solid wire: 26 – 18 AWG / 0,.14 – 0.75 mm
Strapped: 26 – 18 AWG / 0.14 – 0.75 mm
2
Strapped (with termination): 28 – 20 AWG / 0.08 – 0.5 mm
4 Function
The actuator in a Profibus network can be looped through (daisy chain) or used with a
terminating resistor as the end position. Power supply via the standard device plug.
Profibus Codes
With Profibus following codes can be displayed
Signal Typ/ Byte
Bit
Digital Output
(Master Slave)
EACON
Bit 0
Electric
Bit 1
Actuator
Control
Bit 2
Byte
Bit 3
Bit 4
Bit 5 - 7
ACKRST
Bit 0
Bit 1
Bit 2 - 7
POSSET
Bit 0 - 7
Digital Input
(Slave Master)
TYPVLT
Bit 0-3
Bit 4 - 7
STATE
Bit 0
Bit 1
Bit 2
Pin Assignment Socket
Recommended mating connectors:
Phoenix Contact
SACC-M12FSB-2PL SH PB – 1424680
2
2
Aktion
Parameter
Off
Close
On
Open
Middle
Middle
Stop
Stop
Positioner active
positioner enabled
Reserved
reserved
Confirm error
err_ack
Reset cycle
cycle_cntr_reset
counter
Reserved
reserved
Setpoint for
0...100 setpoint range
positioner from 0 -
0= close
100%, when
100 = open
position regulator
101...255 = invalid value
is active
0= EA25
ea_type
1= EA45
2= EA120
3= EA250
0= 24V AC/DC
ea_voltage
1= 100 – 230V AC
Feedback close
limit_switch_closed
Feedback open
limit_switch_open
Feedback middle
limit_switch_middle
Signal Typ/ Byte
Bit
Bit 3
Bit 4
Bit 5
Bit 6 - 7
POSACT
Bit 0 - 7
CURRENT (Wort)
Bit 0 - 15
TEMP
Bit 0 - 7
CYCLES (Doppelwort)
Bit 0 - 31
ERRFLAGS (Doppelwort)
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14 – 31
The monitoring function, cycle time extension, motor current monitoring or cycle
counter can be activated as parameterization data in the GSD file.
CAUTION!
Make sure, that the master/slave will have address ≠ 0.
Addresse 1...125 (via PROFIBUS SetSlaveAddress adjustable)
Factory settings/default address = 126
CAUTION!
If slave addressing is locked, reset it possible via regular factory reset
(SET+CW).
Afterwards Positions must be teached again.
Aktion
Parameter
Actuator moving
actuator_moving
Teaching is active
teaching_active
Ready to operate
ready_relay
Reserved
reserved
Actual value for
position_actual_value
positioner from 0 –
100%
0= Closed
100 =open
101...255 = not valid
Absolute value
motor_current
motor current in
mA
Temperature in °C
temperature_base
at sensor in the
actuator(-
20...100°C)
Numbers plug-in
cycle_counter
cycles since last
reset
Voltage too low
undervoltage
„U"
T too high „O"
over_temp_case
Cycle to long „S"
max_positioning_time
Heating out of
heating
order „H"
Error position
position_detection_failed
detection „e"
Position not
position_out_of_range
specified „P"
Override is
manual_actuation
activated „E"
No communication
accessory_no_reply
with accessory „9"
Fail-safe unit
powerfail_action
activated
Battery voltage
powerfail_accu_lvl_warn
<50% "L"
Battery defect "A"
powerfail_accu_defect
Restart EA via
watchdog_recovery
Watchdog recovery
Motor current
motor_current_overflow
monitoring tripped
"I"
Error motor driver
mot_driver_overload
"b"
Reserved
reserved
