Maintenance
Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
Specifications
Operating voltage
Current consumption
Using 2 inputs
Using 4 inputs
Line resistance
End-of-line resistor
Optional resistor for supervised
inputs
Relay contact rating
Max. switching power
Max. switched current
Max. switched voltage
IP rating
Operating environment
Operating temperature
Storage temperature
Relative humidity
Weight
Dimensions
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation
(EU) 305/2011 and Delegated Regulations (EU) 157/2014 and
(EU) 574/2014.
For detailed information, see the product Declaration of
Performance (available at firesecurityproducts.com).
EU compliance
Certification body
Declaration of
Performance number
Year of first CE marking
Product identification
Intended use
Declared performance
Manufacturer
P/N 10-5106-501-34NC-02 • ISS 01OCT21
17 to 28 VDC
Max. 350 µA
Max. 420 µA
<100Ω
150 kΩ, 5%, 1/4W
33 kΩ, 5%, 1/4W
60 W
2 A
30 VDC
IP40
−10 to +55°C
−20 to +60ºC
10 to 95% noncondensing
100 g
175 × 124 × 51 mm
0370
10-5106-360-3001
18
IO2034NC
See the product Declaration of
Performance
See the product Declaration of
Performance
Carrier Safety System (Hebei) Co. Ltd.,
80 Changjiang East Road, QETDZ,
Qinhuangdao 066004, Hebei, China.
Authorized EU manufacturing
representative:
Carrier Fire & Security B.V.,
Kelvinstraat 7, 6003 DH Weert,
Netherlands
Contact information and product
documentation
For contact information or to download the latest product
documentation, visit firesecurityproducts.com.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS.
CARRIER FIRE & SECURITY B.V. CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED DEALER" OR
"AUTHORIZED RESELLER", IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers
and product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code:
CS: Instalační návod
Popis
Tento dokument obsahuje informace o instalaci
vstupního/výstupního modulu IO2034NC. Modul nabízí čtyři
vstupy a čtyři výstupy a je navržen pro použití
s adresovatelnými požárními systémy FP1200C-2000C a 2X
Series.
Obrázky
Obrázek 1: Sestava modulu
Obrázek 2: Struktura modulu
(1) Kontrolka LED poruchy pro
rozpojený nebo zkratovaný
obvod hlídaných vstupů
(2) Otočné přepínače pro
adresování modulu
(3) Vstup zdrojového napětí
COM2 (kladný)
Obrázek 3: Zapojení plně hlídaného vstupu
Obrázek 4: Příklad nastavení adresy
2012/19/EU (WEEE Directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste
in the European Union. For proper
recycling, return this product to your local
supplier upon the purchase of equivalent
new equipment, or dispose of it at
designated collection points. For more
information see: recyclethis.info.
(4) Vstup zdrojového napětí
COM1 (záporný)
(5) Vstupy A až D
(6) Výstupy A až D (NC, COM,
NO)
