TROUBLESHOOTING
During recording of the RED, the buzzer sounds for 3/5 second
During recording of the RED, the buzzer emits 2 tones
The buzzer emits a tone every 3 seconds and one of the EDGE PHOT LEDs is turned
on red
The gate doesn't move. The buzzer emits an alternating sound and one of the EDGE
PHOT LEDs blinks green/red.
The buzzer does not sound when the batteries are removed from the strip
TECHNICAL FEATURES
- FREQUENCE
- SENSITIVITY
- OUTPUT POWER
- BATTERY FEED
- IDLE ABSORPTION
- MAX ABSORPTION
- MODULATION TYPE
- RANGE
- BATTERY LIFE
- CASE
- SIZE
- PROTECTION LEVEL
- OPERATION TEMPERATURE

ACCESSORIES

3,6V AA LITHIO BATTERIEES
PROBLEM
868,3 MHz
-108 dBm
<25 mW
AA 3,6 V Lithio 2,6 mAh
25 µA
13 mA
FSK
20 m in free space without aerial
2 years
External - Technopolimer
129x89x58 mm
IP56
From -20°C to +60°C
code ACG9517
It has been tried to record a RED with wrong DIP.
Verify that the EDGE PHOT LED that blinks on MASTER Wi-Fi corresponds to the dip on
RED to memorize
RED code is already in the memory
Replace as soon as possible the battery of the RED as it is low
Replace the battery of the RED as it is empty
On the MASTER Wi-Fi, verify that the EDGE PHOT DIP corresponding to the RED is in ON
position
