4 CHANNEL STEREO+ SUBWOOFER
SUB BRIDGED
+ + - + -
- + - + -
SUB BRIDGED
Please observe speaker channel and polarity as printed by the speaker terminal block.
Incorrect phasing of the speakers results in total loss of bass response.
SPEAKER CONNECTIONS
+12V REM
When utilzing the 5 Channel Mode,
you can use an specified inductor
(blocking-coil) in series with the
5th Channel (sub) to optimize your
sound. In order to prevent impedance
overload Frequency Distortion issues.
