DESCRIPTION OF THE DEVICE
1
2
3
4
(7) DMX output
(8) DMX input
(9) USB port for QuickDMX receiver
(10) Safety eyelet
(11) Power input
(12) Power output
(13) Display
(14) Menu button
(15) Up button
(16) Down button
(17) Enter button
7
8
9
10
11
12
13
14
15
16
17
21/32
(1) Housing
(2) Lens/LED
(3) Fixation screw
(4) Infrared sensor for
the remote control
(5) Mounting bracket
(6) Mounting hole
5
6
00142487, Version 1.0
