PROTECTING THE ENVIRONMENT
Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a
disposal which is not harmful to the environment. Devices marked with this symbol must not be
disposed of as household waste. Contact your retailer or local authorities for more information.
Remove any inserted batteries and dispose of them separately from the product.
You as the end user are required by law (Battery Ordinance) to return all used batteries/
rechargeable batteries. Disposing of them in the household waste is prohibited. You may return
your used batteries free of charge to collection points in your municipality and anywhere where
batteries/rechargeable batteries are sold. By disposing of used devices and batteries correctly,
you contribute to the protection of the environment.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
IP classification:
Protection class:
Power connection:
Power output:
Lamp type:
LED:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Construction:
Beam angle (1/2 peak):
Beam angle (1/10 peak):
Housing color:
Attachment system:
Display type:
Dimensions:
Weight:
Noise classification:
Remote control
Battery:
100-240 V AC, 50/60 Hz
36 W
IP20
Class I
Mains input via P-Con (blue), mounting version
power supply cord with safety plug (provided)
P-Con (gray), mounting version
LED lamp
1 x 40 W 4in1 QCL RGBW (homogenous color mix)
3; 4; 6; 8; 11
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
Passive convection
IR remote control; stand-alone; QuickDMX (optional); W-DMX by wireless
solution (optional); CRMX by LumenRadio (optional); DMX; Sound to light via
Microphone; Master/slave function
Easy installation
4°
8°
Black
Double bracket
LCD display
Length: 12 cm
Width: 17 cm
Height: 22,5 cm
1,80 kg
Class 0 (no noise at all)
1 x Button cell 3.0 V CR2032 lithium manganese built-in
31/32
00142487, Version 1.0
